Sahil Metals is a well-respected manufacturer and supplier based in Riyadh, Saudi Arabia, known for its top-notch **Aluminium 5005 Forgings**. These forgings are prized for their outstanding corrosion resistance, durability, and lightweight characteristics. The company is dedicated to precision manufacturing and rigorous quality control, ensuring that their aluminium solutions meet the needs of various sectors, including industrial, architectural, and marine applications. With dependable delivery, expert technical support, and competitive pricing, Sahil Metals offers products that are perfect for industries looking for long-lasting, high-performance aluminium forgings that serve both structural and aesthetic purposes.
Aluminium 5005 Forgings mainly consist of aluminium with about 0.8–1.2% magnesium as the key alloying element, along with small amounts of chromium, iron, and silicon. This alloy is known for its excellent corrosion resistance, especially in marine and atmospheric settings, along with moderate strength, good ductility, and exceptional formability. The typical tensile strength falls between 145–220 MPa, yield strength is around 40–125 MPa, and elongation is approximately 12–25%, making it ideal for forging, shaping, and forming processes.
Standards : ASTM B247, B247
Temper : H34
Specification : DIN, ASTM, BS and all International Standards
Flat bar blocks : up to 27″ width and 15,000 lbs.
Cylinders and sleeves : up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs : up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings : up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts : up to 144″ maximum length and 20,000 lbs.
| Chemical Element | Manganese (Mn) | Iron (Fe) | Copper (Cu) | Magnesium (Mg) | Silicon (Si) | Zinc (Zn) | Chromium (Cr) | Other (Each) | Others (Total) | Aluminium (Al) |
|---|---|---|---|---|---|---|---|---|---|---|
| % Present | 0.0 – 0.20 | 0.0 – 0.70 | 0.0 – 0.20 | 0.50 – 1.10 | 0.0 – 0.30 | 0.0 – 0.25 | 0.0 – 0.10 | 0.0 – 0.05 | 0.0 – 0.15 | Balance |
| Mechanical Property | Tensile Strength | Proof Stress | Hardness Brinell |
|---|---|---|---|
| Value | 145 – 185 MPa | 110 Min MPa | 47 HB |
| European Standard | UNS | GERMANY (DIN) |
| Al-Mg-1 | B57S | A95005 |
Aluminum 5005 offers excellent corrosion resistance, good weldability, formability, and moderate strength, making it ideal for custom forgings in architectural and marine applications, while providing a smooth, aesthetic finish.
Aluminum 5005 is not ideal for high-temperature forging applications. It has moderate strength and good corrosion resistance but lacks the high-temperature stability needed for forging processes.
These Aluminium 5005 Forgings find extensive use in roofing panels, siding, architectural structures, marine fittings, and chemical equipment, thanks to their corrosion resistance and moderate strength. They are also utilized in automotive parts, storage tanks, pipelines, and decorative panels. The lightweight and durable nature of this alloy guarantees long-lasting performance, low maintenance, and reliability in applications that face tough environmental conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Sahil Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Riyadh, Saudi Arabia
