Sahil Metals is a top-notch producer and supplier of high-performance metal products in Riyadh, Saudi Arabia. It deals in supplying top-class Hastelloy bars and rods for application in highly corrosive and aggressive environments. Reputed for its quality focus, timely delivery, and compliance to international standards, Sahil Metals serves markets across chemical processing, power generation, pharmaceuticals, and marine engineering. Empahsing on strength and accuracy, the company provides durable alloy solutions for critical applications calling for world-class resistance to corrosion and extended service life.
Hastelloy rods and bars are nickel-based alloys with differential percentages of elements such as molybdenum, chromium, iron, cobalt, and tungsten based on the type (e.g., C22, C276, B2, or B3). These alloys are best known for their high resistance to both oxidizing and reducing agents. Hastelloy rods and bars possess high tensile strength (commonly 690–800 MPa), good ductility, and high resistance to pitting, crevice corrosion, and stress corrosion cracking. Hastelloy materials do not change their mechanical and chemical properties even in harsh temperatures and corrosive environments, thus suitable for harsh service conditions.
| Dimensions | DIN, EN, ASTM, JIS, ASME, BS, AISI |
|---|---|
| Hastelloy Round Bar size | Diameter: 3-~800mm |
| Hastelloy Flat bar size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Hastelloy Bar Angle size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Rectangular Bars Section | 3.0 to 12.0mm thickness |
| Billet Size | 1/2 to 495mm Diameter |
| Rectangles Size | 33 x 30mm to 295 x 1066mm |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Dimensions | Diameter / Height |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Surface | Hot Rolled Pickled, Bright, Sand Blasting Finished, Cold Drawn, Hairline,Polished |
| Condition | Hardened & tempered, annealed |
| Technique | Stainless Steel Cold Drawn, Hot Rolled, Forged Round Bar,Cold Rolled, Rod |
| Processing | Bar cutting to 650mm |
| Form | Rod, Round, Channel Bar, T-Bar, Flat Bar, Precision Ground Bar, Blocks, Square, Rings, Round Rod, Triangle, Hollow, Rectangle, Threaded, Hex (A/F), Profiles, Half Round Bar, Ingot, Billet, I/H Bar, Forging etc. |
| Grade | UNS | Cr | Mo | Fe | C≤ | Si≤ | Co≤ | Mn≤ | P≤ | S≤ |
| B2 | N10665 | 1.0max | 26.0-30.0 | 2.0max | 0.02 | 0.10 | 1.0 | 1.0 | 0.04 | 0.03 |
| B3 | N10675 | 1.0-3.0 | 27.0-32.0 | 1.0-3.0 | 0.01 | 0.10 | 3.0 | 3.0 | 0.03 | 0.01 |
| X | N06002 | 20.5-23.0 | 8.0-10.0 | 17.0-20.0 | 0.05-0.15 | 1.0 | 0.5-2.5 | 1.0 | 0.04 | 0.03 |
| C22 | N06022 | 20.0-22.5 | 12.5-14.5 | 3.0-6.0 | 0.015 | 0.08 | 2.5 | 0.5 | 0.02 | 0.02 |
| C2000 | N06200 | 22.0-24.0 | 15.0-17.0 | 3.0max | 0.01 | 0.08 | 2.0 | 0.5 | 0.025 | 0.01 |
| C276 | N10276 | 14.5-16.5 | 15.0-17.0 | 4.0-7.0 | 0.01 | 0.08 | 2.5 | 1.0 | 0.04 |
| Mechanical properties | Tensile, min, ksi[MPa] | Yield, min, ksi[MPa] | Elongation, %(min) |
| B2 | 110[760] | 51[350] | 40 |
| B3 | 110[760] | 51[350] | 40 |
| X | 100[690] | 40[276] | 35 |
| C22 | 100[690] | 45[310] | 45 |
| C2000 | 100[690] | 45[310] | 45 |
| C276 | 100[690] | 41[283] | 40 |
Yes, Hastelloy Bars are highly corrosion-resistant, making them ideal for harsh environments, including chemical processing and marine applications. They resist pitting, crevice corrosion, and stress corrosion cracking effectively.
Yes, Hastelloy Rods can be customized in size and length to meet specific industry requirements. Their versatility ensures suitability for diverse applications.
Hastelloy bars perform exceptionally in high-temperature environments, offering thermal stability, oxidation resistance, and strength retention. They are ideal for demanding applications like chemical processing and aerospace.
Hastelloy bars and rods are used extensively across industries that experience highly corrosive or high-temperature operating conditions. Some of the applications include chemical reactors, heat exchangers, pressure vessels, marine parts, pharmaceutical equipment, and pollution control equipment. Their versatility and resistance to strong acids like hydrochloric and sulfuric acid make them suitable for use in both oxidizing and reducing conditions. Engineers rely on Hastelloy for critical applications that require long-term durability, structural integrity, and resistance to corrosion-induced failure under harsh chemical exposure and thermal cycling.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
