Sahil Metals is a Riyadh, Saudi Arabia-based reliable manufacturer and supplier of high-performance metal solutions to industries with high operational requirements. One of Sahil Metals’ major products is Hastelloy C22 bars and rods, commonly known for their superior corrosion resistance and longevity in harsh chemical environments. Sahil Metals offers precision-engineered materials conforming to global quality standards, catering to industries like chemical processing, marine, power generation, and pharmaceuticals. Focusing on customer satisfaction, prompt delivery, and technical consistency, Sahil Metals remains a trusted partner for state-of-the-art alloy needs.
Bars and rods of Hastelloy C22 consist mainly of nickel, with major content of chromium (20-22.5%), molybdenum (12.5-14.5%), and iron (2-6%), plus tungsten. This composition provides superior resistance to vast corrosive media such as oxidizing and reducing agents. The alloy shows high tensile strength (approximately 690 MPa), superior ductility, and remarkable resistance to pitting, crevice corrosion, and stress corrosion cracking. Due to its corrosion resistance and mechanical stability, the alloy is particularly effective under aggressive conditions encompassing acids, chlorides, and high temperatures, providing long service life and negligible degradation with time.
| Standard | ASTM B574, ASME SB574 |
| Round Bar Size | 3mm~ 800mm |
| Square Bar Size | 4mm* 4mm ~100mm* 100mm |
| Flat Bar Size | 2mm ~ 100mm |
| Hex Bar Size | 2mm ~ 100mm |
| Angle Size | 3mm* 20mm* 20mm~ 12mm* 100mm* 100mm |
| Thickness | 50 mm to 6000 mm Long |
| Length | 1 To 6 Meters, Custom Cut Length |
| Form | Round, Square, Hex(A/F), Rectangle, Billet, Ingot, Forging Etc |
| Grade | Ni | C | Cr | Co | Fe | Mn | Mo | P | Si | S | W | V |
| Hastelloy C22 | Bal | 0.010 max | 20 – 22.5 | 2.5 max | 2 – 6 | 0.50 max | 12.5 – 14.5 | 0.02 max | 0.08 max | 0.02 max | 2.5 – 3.5 | 0.35 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.69 g/cm3 | 1399 °C (2550 °F) | Psi – 1,00,000 , MPa – 690 | Psi – 45000 , MPa – 310 | 45 % |
| STANDARD | WERKSTOFF NR. | UNS | GOST | AFNOR | JIS | OR | EN |
| Hastelloy C22 | 2.4602 | N06022 | – | – | NW 6022 | – | NiCr21Mo14W |
| ALLOY C-22 (Ni/22Cr/13Mo/3Fe/3W) / INCONEL 622/C-22 Round Bar | Dimension |
|---|---|
| cold drawn, solution annealed | Dia=16.0 mm, Weight=1.75 kg/m |
| hot worked, solution annealed, peeled | Dia=20.0 mm, Weight=2.6 kg/m |
| hot worked, solution annealed, peeled | Dia=25.4 mm, Weight=4.5 kg/m |
| hot worked, solution annealed, peeled | Dia=30.0 mm, Weight=6.14 kg/m |
| hot worked, sol annealed, peeled | Dia=38.1 mm, Weight=10.1 kg/m |
| extruded, machined, solution annealed | Dia=45.0 mm, Weight=13.15 kg/m |
| hot worked, solution annealed, peeled | Dia=50.8 mm, Weight=18.0 kg/m |
| extruded, machined, solution annealed | Dia=70.0 mm, Weight=35.0 kg/m |
| solution annealed, peeled | Dia=82.55 mm, Weight=47.6 kg/m |
| hot worked, solution annealed, peeled | Dia=101.6 mm, Weight=72.1 kg/m |
| forged, solution annealed, peeled | Dia=115.0 mm, Weight=89.4 kg/m |
| forged, solution annealed, peeled | Dia=130.0 mm, Weight=113.9 kg/m |
| forged, solution annealed, peeled | Dia=150.0 mm, Weight=152.15 kg/m |
| forged, turned | Dia=165.1 mm, Weight=187 kg/m |
Yes, Hastelloy C22 Bars are highly corrosion-resistant, particularly against pitting, crevice corrosion, and stress corrosion cracking in harsh environments. They excel in resisting acids, oxidizing agents, and chloride-induced corrosion.
Yes, Hastelloy C22 rods can be customized in size and length to meet specific industrial requirements. Manufacturers often offer tailored dimensions to suit diverse applications.
Hastelloy C22 bars perform exceptionally well in high-temperature environments due to their superior resistance to oxidation and thermal stability. They maintain strength and corrosion resistance under extreme conditions.
Hastelloy C22 rods and bars are widely utilized in processes like pollution control, chemical processing, pulp and paper, marine, and waste treatment. Bars are suitable for handling such aggressive materials as seawater, wet chlorine, ferric and cupric chlorides, and nitric acid. Typical applications involve flue gas desulfurization systems, ducts, scrubbers, heat exchangers, and reactor vessels. Their resistance to localized attack and mechanical integrity under harsh conditions makes them the go-to choice for mission-critical devices faced with corrosive fluids and thermal cycling over prolonged time periods.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Sahil Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Riyadh, Saudi Arabia
