Khaleed Stainless is a well-respected manufacturer and supplier of high-quality stainless steel products, proudly based in Riyadh, Saudi Arabia. One of their standout offerings is the **Stainless Steel 904L Bars and Rods**, crafted specifically for applications that demand exceptional corrosion resistance and strength. These bars are renowned for their performance in tough chemical and marine environments, and they’re produced to meet international standards, ensuring high dimensional accuracy and a superb surface finish. Khaleed Stainless caters to various industries, including chemical processing, pharmaceuticals, marine, and pulp & paper, providing products that promise long-lasting durability and resilience in challenging conditions.
Stainless Steel 904L is a high-alloy austenitic stainless steel that boasts around 25% nickel, 20% chromium, 4.5% molybdenum, and a touch of copper, which together provide remarkable resistance to strong reducing acids and corrosion from chlorides. Typically, these bars and rods exhibit tensile strength ranging from 490 to 710 MPa and yield strength of about 220 MPa. Despite its rich alloy composition, 904L remains easy to weld and form, showcasing good toughness and low carbon content to prevent intergranular corrosion. These characteristics make 904L an excellent choice for extreme environments where standard stainless steels might falter, ensuring both structural integrity and corrosion protection.
| Grade | SS 904L – UNS N08904 |
|---|---|
| Specification | ASTM A276 UNS N08904, WS 1.4539, AFNOR Z2CNDU 25-20 |
| Round bar size | Diameter: 3-~800mm |
| Hex Bar size | 2-100mm A/F |
| Flat bar size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Square bar size | 4 to 100mm |
| Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Section | 3.0 to 12.0mm thickness |
| Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 904Lmm ID) |
| Billet Size | 1/2″ to 495mm Diameter |
| Rectangles Size | 33 x 30mm to 295 x 1066mm |
| Round Bar Standard Dimensions | Diameter / Height: |
| Finish | Cold (bright) drawn, centreless ground,smooth turned, peeled, slit rolled edge, hot rolled, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Surface | Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished, Polished, Hairline |
| Condition | Hardened & tempered, annealed |
| Technique | Stainless Steel 904L Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar, Rod |
| Processing | Bar cutting to 650mm |
| Form | Stainless Steel 904L Welding Rod, Round, Rod, T-Bar, Channel Bar, Precision Ground Bar, Flat Bar, Square, Blocks, Round Rod, Rings, Hollow, Triangle, Rectangle, Hex (A/F), Threaded, Half Round Bar, Profiles, Billet, Ingot, I/H Bar, Forging etc. |
| Our stockyad location for fast delivery across India | Coimbatore, Bhubaneswar, Ahmedabad, Bengaluru, Thiruvananthapuram, Agra, Chennai, Noida, Mumbai, Shivamogga, Dhanbad, Hyderabad, Tiruchirappalli, Tirunelveli, Pune, Pimpri-Chinchwad, Navi Mumbai |
| Our Stainless Steel 904L Round bar conforms to NACE MR0175/ISO 15156 | |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Cu |
|---|---|---|---|---|---|---|---|---|---|
| SS 904L | 0.020 max | 2 max | 1 max | 0.040 max | 0.030 max | 19.0-23.0 | 4.0-5.0 max | 23.00 – 28.00 | 1.0-2.0 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 7.95 g/cm3 | 1350 °C (2460 °F) | Psi – 71000 , MPa – 490 | Psi – 32000 , MPa – 220 | 35% |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | KS | AFNOR | EN |
|---|---|---|---|---|---|---|---|
| SS 904L | 1.4539 | N08904 | SUS 904L | 904S13 | STS 317J5L | Z2 NCDU 25-20 | X1NiCrMoCu25-20-5 |
Stainless Steel 904L is a high-alloy, corrosion-resistant material that contains significant amounts of nickel, chromium, and molybdenum. It is designed for use in highly corrosive environments, offering excellent resistance to acids, particularly sulfuric acid, and chloride corrosion. It is commonly used in chemical processing, marine, and pharmaceutical industries.
The key benefits of Stainless Steel 904L Bars and Rods include exceptional resistance to corrosion, excellent weldability, and good formability. These properties make them ideal for applications in aggressive chemical environments, marine applications, and other high-performance settings.
Stainless Steel 904L Bars and Rods find extensive use in industries frequently exposed to corrosive media and high stress. In chemical and petrochemical processing, they are perfect for handling sulfuric, phosphoric, and acetic acids. In marine settings, you’ll find them in seawater cooling systems, propeller shafts, and offshore platforms, thanks to their resistance to chlorides. The pharmaceutical and food industries also appreciate them for their cleanliness and non-reactive nature. Additionally, these bars and rods are utilized in heat exchangers, condensers, and pollution control systems, making them a versatile choice across various applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
