Sahil Metals, based in Riyadh, Saudi Arabia, stands out as a leading manufacturer and supplier of high-quality metal products, offering customized solutions for a variety of industrial sectors. With a strong commitment to quality, durability, and adherence to international standards, Sahil Metals provides an extensive selection of Stainless Steel 316L Bars and Rods. Renowned for their exceptional corrosion resistance and impressive mechanical properties, these products are perfect for challenging environments. Sahil Metals proudly caters to industries such as marine, chemical processing, food and beverage, and pharmaceuticals, supplying reliable stainless steel materials designed for long-lasting, high-performance applications.
Stainless Steel 316L Bars and Rods are low-carbon variants of 316 stainless steel, crafted to deliver outstanding corrosion resistance and enhanced weldability. Their chemical makeup consists of roughly 16–18% chromium, 10–14% nickel, 2–3% molybdenum, and a maximum carbon content of 0.03%. These bars boast a tensile strength of about 485 MPa, yield strength of 170 MPa, and an elongation of around 40%. The inclusion of molybdenum boosts resistance to pitting and crevice corrosion, especially in chloride-rich or acidic settings, making 316L an excellent choice for harsh industrial conditions.
| Specification | ASTM A276/ A479, ASME SA276/SA479 |
|---|---|
| Grade | Stainless Steel 316L (UNS S31603) |
| Flat bar size | 1/2” to 10” in thickness range of 2mm to 150mm |
| Square bar size | 18mm – 47mm (11/16″ to 1-3/4″) |
| Round bar size | Outside Diameter in the range of 4mm to 500mm |
| Hex Bar size | 18mm – 57mm (11/16″ to 2-3/4″) |
| Bright Bar | Outside Diameter in the range of 4mm to 100mm |
| Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Billet Size | 1/2″ to 495mm Diameter |
| Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Rectangular bar Size | 33 x 30mm to 295 x 1066mm |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Surface | Cold Drawn, Bright, Sand Blasting Finished, Hot Rolled Pickled, Hairline, Polished |
| Condition | Hardened & tempered, annealed |
| Technique | 316L Stainless Steel Cold Drawn, Hot Rolled, Forged Round Bar, Rod, Cold Rolled |
| Processing | Bar cutting to 650mm |
| Section | 3.0 to 12.0mm thickness |
| Form | Precision Ground Bar, Flat Bar, Square, Round, Half Round Bar, Rod, Rectangle, Hex (A/F), T-Bar, Channel Bar,Blocks, Round Rod, Threaded, Profiles, Billet, Ingot, I/H Bar, Forging, Rings, Hollow, Triangle etc. |
| Our 316L Stainless Steel Round bar conforms to NACE MR0175/ISO 15156 | |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 316L | 0.3 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 16 – 18 | 2 – 3 | 10 – 14 | 0.10 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1454 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 40 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316L | 1.4404 / 1.4435 | S31603 | SUS 316L | 316S11 / 316S13 | 03Ch17N14M3 / 03Ch17N14M2 | Z3CND17‐11‐02 / Z3CND18‐14‐032 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 |
Stainless Steel 316L contains molybdenum, which enhances resistance to chloride-induced pitting and corrosion, making it highly suitable for marine and coastal applications.
Yes, the low carbon content in 316L minimizes carbide precipitation during welding, ensuring excellent corrosion resistance even in heat-affected zones.
Stainless Steel 316L Bars and Rods find widespread application in marine, chemical, pharmaceutical, food processing, and medical industries due to their remarkable resistance to corrosion, particularly in saltwater and acidic environments. Their low carbon content helps prevent carbide precipitation during welding, ensuring structural integrity and long-term corrosion resistance. These bars and rods are frequently utilized in the production of valves, pumps, heat exchangers, shafts, and structural components. Their strength, formability, and hygienic properties make them a top choice for both industrial and sanitary applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Sahil Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Riyadh, Saudi Arabia
