Sahil Metals, located in Riyadh, Saudi Arabia, has made a name for itself as a trusted manufacturer and supplier of high-quality metal products. They’re particularly known for their reliable and durable stainless steel solutions that cater to a variety of industrial sectors. One standout product is the Stainless Steel 304L Hex Bar/Rod, which is perfect for structural and engineering applications that demand excellent corrosion resistance and formability. These hex bars/rods are crafted to meet international standards, ensuring superior weldability and performance in both mild and harsh environments. Sahil Metals proudly serves key industries like construction, petrochemicals, marine, and food processing, offering materials designed for strength, longevity, and efficient fabrication.
The Stainless Steel 304L Hex Bar/Rod is a low-carbon austenitic stainless steel that contains 18–20% chromium, 8–12% nickel, and a maximum carbon content of 0.03%. This lower carbon content enhances resistance to intergranular corrosion after welding while still maintaining strength and ductility. These bars boast a tensile strength of about 485 MPa, a yield strength of 170 MPa, and an elongation of roughly 40%. The hexagonal shape not only makes machining easier but also provides a better grip in mechanical assemblies, making 304L an excellent choice for structural and precision components that are exposed to moisture or chemicals.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 304L | 8.0 – 11.0 | 18.0 – 20.0 | 2.0 max | 8.0 – 12.0 | 0.045 max | 0.03 max | 1.0 max |
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 304L | 8.0 – 11.0 | 18.0 – 20.0 | 2.0 max | 8.0 – 12.0 | 0.045 max | 0.03 max | 1.0 max |
| Element | Density, lb/in3 | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| SS 304L | 8.0 g/cm3 | 1400 °C (2550 °F) | 485 | 170 | 40 |
| HEXAGONS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
SS 304L hex bars/rods are typically available in sizes ranging from 3.17mm to 350mm in diameter, with lengths of 2 to 7.5 meters. These bars come in various finishes, such as polished or cold-drawn. Custom sizes and specifications can also be produced upon request to meet specific needs.
Yes, SS 304L hex bars/rods are highly weldable and suitable for fabrication into complex shapes. Their low carbon content minimizes carbide precipitation during welding, reducing the risk of corrosion. This material's excellent ductility and toughness allow easy forming, machining, and fabrication, making it ideal for intricate designs and applications.
SS 304L has lower carbon content than standard 304, reducing carbide precipitation and enhancing corrosion resistance, particularly after welding. While slightly lower in strength compared to higher-carbon grades like 304 or 316, it maintains excellent toughness and durability. SS 316 offers superior corrosion resistance in chloride environments due to added molybdenum.
You’ll find Stainless Steel 304L Hex Bars and Rods commonly used in structural frameworks, fasteners, marine equipment, heat exchangers, and food processing machinery. Their impressive corrosion resistance and weldability make them ideal for environments that deal with chemicals, moisture, or fluctuating temperatures. The hexagonal cross-section allows for superior torque handling, making these rods perfect for machining into nuts, bolts, and precision fittings. Plus, they’re widely used in architectural supports, pharmaceutical equipment, and sanitary applications where hygiene, strength, and long-lasting performance are crucial.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Sahil Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Riyadh, Saudi Arabia
