Sahil Metals, located in Riyadh, Saudi Arabia, has made a name for itself as a top-notch manufacturer and supplier of premium stainless steel products. They specialize in providing advanced material solutions that cater to the unique needs of critical industries. One standout product in their lineup is the **Stainless Steel 15-5 PH Hex Bar/Rod**. This precipitation-hardening stainless steel is celebrated for its impressive strength, exceptional corrosion resistance, and remarkable toughness. Designed for tough structural and mechanical applications, these bars are perfect for sectors like aerospace, petrochemical, marine, and nuclear industries. Sahil Metals is committed to delivering reliable performance and precision, ensuring their stainless steel products meet rigorous industry standards and are built to last.
The Stainless Steel 15-5 PH Hex Bar/Rod is a martensitic, precipitation-hardening stainless steel that contains about 15% chromium, 4–5% nickel, 2.5–4.5% copper, and a maximum carbon content of 0.07%. This alloy achieves its high strength and hardness through heat treatment, boasting a tensile strength of up to 1310 MPa and a yield strength around 1170 MPa, with good elongation ranging from 10–15%. It offers excellent corrosion resistance, enhanced toughness compared to 17-4 PH, and outstanding mechanical properties, making it ideal for critical applications that demand both strength and resistance to cracking under stress.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Grade | C | Cb+Ta | Cr | Cu | Fe | Mn | Ni | P | S | Si |
| SS 15-5 PH | 0.07 max | 0.15-0.45 max | 14.0-15.0 max | 2.5-4.5 max | Bal | 1.0 | 3.5-5.5 | 0.04 | 0.03 | 1.0 |
| Grade | Tensile Strength ksi (MPa) | Yield Strength 0.2% ksi (min) | Elongation % | Hardness (Rockwell) MAX |
| SS 15-5 PH | 161,000 | 140,000 | 7.6% | C35 |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 15-5PH | 1.4545 | S15500 |
| HEXAGONS | ||
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Store Stainless Steel 15-5 PH hex bars and rods in a clean, dry, ventilated area, elevated on racks, with protective covers, separated from other metals, and handled carefully.
Stainless Steel 15-5 PH hex bars excel in wear-resistant applications due to their high strength, toughness, excellent corrosion resistance, and ability to maintain hardness after precipitation-hardening heat treatment.
Common challenges with Stainless Steel 15-5 PH hex bars include susceptibility to stress corrosion cracking in chloride environments, limited ductility in hardened conditions, higher machining difficulty, and potential distortion during heat treatment.
You’ll find Stainless Steel 15-5 PH Hex Bars and Rods in a variety of applications, including aerospace components, high-strength fittings, nuclear reactor parts, shafts, fasteners, and pressure-containing structures. Their impressive strength, toughness, and corrosion resistance make them perfect for extreme environments, such as marine and chemical processing applications. These hex bars also provide superior machinability and dimensional stability after heat treatment, making them a great choice for precision manufacturing and high-load structural designs. Plus, their shape enhances grip and torque resistance, which is crucial for fastening and mechanical assemblies that face repeated stress and dynamic loads.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
