Sahil Metals stands out as a top manufacturer and supplier in Riyadh, Saudi Arabia, specializing in high-quality aluminium products like Aluminium 5754 Bars and Rods. These products are well-known for their impressive corrosion resistance, good weldability, and medium-to-high strength, all crafted to meet international quality standards. At Sahil Metals, every item is designed with durability, precision, and reliability in mind, catering to various industries such as marine, automotive, chemical processing, and construction. With a strong focus on customer satisfaction and excellence, the company provides Aluminium 5754 Bars and Rods that promise long-lasting performance, versatility, and exceptional value for a wide array of applications throughout Saudi Arabia.
Aluminium 5754 Bars and Rods are primarily made of aluminium with magnesium (2.6–3.6%) and small amounts of manganese, chromium, and iron, which contribute to their corrosion resistance and strength. This alloy boasts a tensile strength of 190–240 MPa and a yield strength of 80–130 MPa, depending on the temper. While it can’t be heat-treated, it excels in weldability, machinability, and offers robust resistance to seawater, industrial pollutants, and stress corrosion cracking. Additionally, Aluminium 5754 Bars and Rods maintain stability and formability, making them perfect for demanding engineering tasks.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Mg | Mn | Si | Cu | Fe | Cr | Zn | Ti | Cu | Other (Each) | Others (Total) | Al |
| 2.60 – 3.60 | 0.0 – 0.50 | 0.0 – 0.40 | 0.0 – 0.40 | 0.0 – 0.30 | 0.0 – 0.20 | 0.0 – 0.15 | 0.0 – 0.10 | 0.0 – 0.05 | 0.0 – 0.05 | 0.0 – 0.15 | Balance |
| Proof Stress | Tensile Strength | Elongation at 50 mm | Hardness Brinell |
| 80 Min MPa | 190 – 260MPa | 12 Min % | 52 HB |
| UNS | EN | DIN | ISO | USA | WNR |
| A95754 | EN AW-5754 | AlMg3 | AlMg3 | AA5754 | 3.3535 |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 5754 bars and rods are suitable for structural applications due to their excellent strength, corrosion resistance, and formability, making them ideal for use in marine, automotive, and architectural structures.
Yes, Aluminium 5754 bars can be welded using various techniques, such as MIG and TIG welding. However, proper welding procedures and equipment are essential to maintain its strength and integrity.
Aluminium 5754 bars are typically sized based on diameter and length. The diameter can range from a few millimeters to several inches, while the length is often available in standard lengths, typically up to 6 meters. Custom sizes can also be ordered based on specific requirements. The bars are available in various shapes, including round, square, and hexagonal, to suit different applications.
These bars and rods are extensively used in marine structures, shipbuilding, and offshore platforms thanks to their outstanding resistance to seawater. They’re also found in automotive panels, transportation vehicles, chemical processing equipment, and storage tanks where corrosion resistance and durability are essential. Plus, their lightweight properties and long-term performance make them ideal for architectural applications, pipelines, and pressure vessels. The combination of strength, corrosion resistance, and workability makes Aluminium 5754 Bars and Rods a go-to choice across various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
