Sahil Metals has made quite a name for itself as a leading manufacturer and supplier in Riyadh, Saudi Arabia, specializing in top-notch aluminium products like Aluminium 5086 Bars and Rods. These products are celebrated for their impressive corrosion resistance, robust strength, and outstanding performance even in the toughest conditions. Crafted to adhere to global quality standards, Sahil Metals guarantees precision, durability, and reliability in every item they produce. They cater to a variety of industries, including marine, automotive, aerospace, and structural engineering. With a strong focus on quality and customer satisfaction, the company provides Aluminium 5086 Bars and Rods that deliver long-lasting performance, versatility, and exceptional value for various applications throughout Saudi Arabia.
Aluminium 5086 Bars and Rods are primarily made of aluminium, with magnesium content ranging from 3.5% to 4.5%, along with trace amounts of manganese (0.2% to 0.7%) and chromium (0.05% to 0.25%). This combination results in a high-strength, corrosion-resistant alloy. They boast excellent resistance to seawater and harsh environments, with tensile strength between 275 and 350 MPa and yield strength from 125 to 200 MPa. The alloy is known for its great weldability, good machinability, and remarkable resistance to stress corrosion cracking. While Aluminium 5086 Bars and Rods are non-heat-treatable, they maintain impressive stability and performance even under demanding industrial conditions.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| GRADE | Si | Ir | Cu | Mn | Mg | Cr | Zn | Ti | Others, each | Others, total | Al |
| 5086 | 0.4 | 0.5 | 0.1 | 0.20-0.70 | 3.5-4.5 | 0.05-0.25 | 0.25 | 0.15 | 0.05 | 0.15 | Balance |
| Properties | Proof Stress | Tensile Strength | Hardness Brinell | Elongation |
| Metric | 125 Min MPa | 275 – 350 MPa | 75 HB | 12 Min % |
| European Standard | OLD | WNr | UNS | ISO | USA (AA) | GERMANY (DIN) |
| AW-AlMg4 | AG4MC | 3.3545 | A95086 | AlMg4 | 5086 | AlMg4Mn |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 5086 bars are fully recyclable. Aluminium is a sustainable material that can be recycled repeatedly without losing its properties, making it an environmentally friendly option for various applications.
Yes, Aluminium 5086 bars and rods can be used for potable water applications due to their corrosion resistance and durability, making them suitable for marine environments and water treatment systems.
When installing Aluminium 5086 bars and rods, consider factors such as proper handling to avoid damage, ensuring compatibility with other materials, and protecting against corrosion by using appropriate coatings or finishes.
These Aluminium 5086 Bars and Rods find extensive use in shipbuilding, offshore structures, and marine equipment, thanks to their exceptional resistance to seawater corrosion. They’re also utilized in automotive components, aerospace structures, pressure vessels, and transportation vehicles that require high strength and durability. Furthermore, these bars and rods are ideal for pipelines, chemical processing equipment, and structural frameworks where reliability and lightweight properties are crucial. Their unique blend of strength, corrosion resistance, and versatility makes Aluminium 5086 Bars and Rods a top choice across various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
