Sahil Metals is a well-respected manufacturer and supplier based in Riyadh, Saudi Arabia, specializing in top-notch aluminium products like Aluminium 2017 Bars and Rods. These products are celebrated for their impressive strength, hardness, and outstanding machinability, making them perfect for tough industrial needs. At Sahil Metals, the focus is on precision, durability, and meeting international standards, catering to sectors such as aerospace, automotive, marine, and heavy engineering. With a strong dedication to quality and ensuring customer satisfaction, the company provides Aluminium 2017 Bars and Rods that deliver reliable performance, versatility, and long-lasting value for a variety of applications throughout Saudi Arabia.
Aluminium 2017 Bars and Rods are primarily made of aluminium, with copper (3.5–4.5%), magnesium (0.4–0.8%), and manganese (0.4–1.0%) mixed in, resulting in a high-strength, heat-treatable alloy. They boast excellent machinability, good fatigue resistance, and impressive tensile strength ranging from 400–460 MPa, along with a yield strength of 240–280 MPa. While they offer only moderate resistance to corrosion, their strength and wear resistance make them ideal for structural and engineering uses. Aluminium 2017 Bars and Rods maintain their shape and performance even under high stress.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| Grade | Al | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Others Each | Other Total |
| 2017 | Rem | 0.20-0.8 | 0.7 max | 3.5-4.5 | 0.40-1.0 | 0.40-0.8 | 0.10 max | 0.25 max | 0.15 max | 0.05 max | 0.15 max |
| Material | Condition | Tensile Strength (N/mm²) min | Yield Strength | Elongation in 4D % | ||
| ksi | Mpa | ksi | Mpa | |||
| 2017 | 2017-T4 Bar | 55 | 379 | 32 | 221 | 12 |
| STANDARD | UNS | WERKSTOFF NR. |
| Aluminium 2017 | A92017 | 3.1325 |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 2017 can be welded, but it requires careful control due to its high strength and susceptibility to cracking. Specialized welding techniques like TIG or MIG are recommended.
To maintain Aluminium 2017, regularly clean with mild detergent and water, avoid abrasive materials, store in a dry environment, and prevent exposure to corrosive substances to preserve its strength and appearance.
Aluminium 2017 rods are typically sized by diameter and length. Common diameters range from 1/8 inch to several inches, while lengths can vary from a few feet to custom sizes based on needs.
These bars and rods find extensive use in aerospace components, aircraft structures, and automotive parts that require a high strength-to-weight ratio and toughness. They’re also utilized in defense equipment, precision machinery, gears, shafts, and rivets where strength and machinability are crucial. Furthermore, these products are perfect for heavy-duty engineering tasks and structural frameworks that demand durability and resistance to fatigue. The blend of strength, machinability, and reliability makes Aluminium 2017 Bars and Rods a top choice across essential industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
