Sahil Metals, located in Riyadh, Saudi Arabia, is a reliable manufacturer and supplier of top-notch **Titanium Grade 7 Forgings**, crafted for outstanding corrosion resistance in tough chemical environments. Known for our commitment to high-quality and precision-engineered titanium products, Sahil Metals guarantees that all our forgings comply with international standards. We proudly serve clients throughout Saudi Arabia and the Middle East, offering dependable solutions tailored to industries like chemical processing, marine engineering, and power generation, where material performance is crucial.
Our Titanium Grade 7 Forgings are made from commercially pure titanium, enhanced with a touch of palladium (0.12%–0.25%), which significantly boosts resistance to crevice corrosion and minimizes acid attack. This grade retains the excellent formability, weldability, and mechanical properties of Grade 2, boasting a tensile strength of around 345 MPa. It stands out for its resistance to chlorides and strong reducing agents, making it ideal for critical components that face harsh or fluctuating chemical conditions.
| Specifications | ASTM B381, ASME SB381 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | N | O | H | Ti | Fe | Al | Pd |
| Titanium Gr 7 | 08 max | 03 max | 25 max | 015 max | Bal | 0.30 max | – | .12 – .25 |
| 0.2% Proof Stress MPa | Tensile Strength MPa | Elongation % |
| 275-475 | 345 | 20 |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 7 | 3.7235 | R52400 |
Yes, Titanium Grade 7 (Ti-0.2Pd) is highly corrosion-resistant, especially in harsh environments like seawater and acidic conditions, due to the addition of palladium, enhancing its ability to resist corrosion.
Titanium Grade 7 forgings are commonly used in industries like aerospace, chemical processing, marine, medical, and power generation due to their exceptional corrosion resistance, strength, and biocompatibility in challenging environments.
Titanium Grade 7 forgings are available in various sizes and shapes, including bars, billets, rings, discs, and custom configurations, typically ranging from small to large diameters for different industrial applications.
You’ll find Titanium Grade 7 Forgings in applications like chemical reactors, heat exchangers, valves, flanges, and piping systems where top-notch corrosion resistance is a must. Industries such as chlor-alkali production, paper and pulp, and offshore oil and gas reap the benefits of its long service life and minimal maintenance needs. Its remarkable resistance to corrosion in both oxidizing and reducing environments ensures reliable performance in demanding industrial settings.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Sahil Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Riyadh, Saudi Arabia
