Sahil Metals, based in Riyadh, Saudi Arabia, stands out as a top manufacturer and supplier of high-performance **Titanium Grade 5 Forgings**. These forgings are highly sought after in industries that require outstanding strength, resistance to corrosion, and lightweight characteristics. With a reputation for providing reliable and precision-engineered titanium products, Sahil Metals guarantees that each forging adheres to rigorous international standards. We proudly serve a diverse clientele throughout Saudi Arabia and the Middle East, offering tailored Titanium Grade 5 solutions for critical applications in aerospace, marine, medical, and industrial sectors.
Titanium Grade 5 Forgings (Ti-6Al-4V) are crafted from an alpha-beta alloy that includes 6% aluminum and 4% vanadium, delivering remarkable mechanical properties and corrosion resistance. With a tensile strength ranging from about 900 to 1000 MPa, these forgings strike a perfect balance between high strength, good ductility, and fatigue resistance. They remain stable even in high-temperature settings and can be welded effectively when the right procedures are followed. This alloy is the go-to choice for titanium due to its exceptional strength-to-weight ratio and reliable performance in tough conditions.
| Specifications | ASTM B381, ASME SB381 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | Ti | C | Fe | H | N | O | Al | V |
| Ti Grade5 | 90 min | – | 0.25 max | – | – | 0.2 max | 6 min | 4 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium Gr. 5 | 4.43 g/cm3 | 1632 °C (2970 °F) | Psi – 138000 , MPa – 950 | Psi – 128000 , MPa – 880 | 14 % |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 5 | 3.7165 | R56400 |
Durability of Titanium Grade 5 forgings is ensured by proper heat treatment, controlled forging process, precise die design, alloy composition, and maintaining optimal surface finish, enhancing strength, corrosion resistance, and fatigue resistance.
Titanium Gr 5 forgings are commonly used in aerospace, automotive, medical, marine, and defense industries, providing high strength, corrosion resistance, and lightweight properties for critical components and high-performance applications.
Closed-die forging in Titanium Gr 5 production involves shaping titanium by compressing it between two shaped dies, ensuring precise dimensions, high strength, and improved material properties for demanding applications.
You’ll find Titanium Grade 5 Forgings in a variety of applications, including aerospace structures, turbine components, medical implants, marine hardware, and high-performance automotive parts. Their impressive strength, lightweight nature, and resistance to corrosion make them perfect for critical uses like engine mounts, aircraft landing gear, surgical instruments, and offshore equipment. Grade 5 titanium forgings provide a dependable and cost-effective solution for challenging environments where strength, fatigue resistance, and durability are key.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
