Sahil Metals, based in Riyadh, Saudi Arabia, stands out as a top manufacturer and supplier of premium **Titanium Grade 1 Forgings**. These forgings are perfect for applications that demand outstanding corrosion resistance and remarkable formability. As a reputable player in the metal industry, Sahil Metals guarantees that every forging adheres to rigorous international quality standards, ensuring high purity, structural reliability, and precise dimensions. We cater to a diverse array of industries throughout Saudi Arabia and the Middle East, providing titanium forging solutions that excel even in the toughest conditions.
Our Titanium Grade 1 Forgings are crafted from commercially pure titanium, featuring the lowest oxygen content (up to 0.18%), which translates to exceptional ductility and corrosion resistance. With a tensile strength of around 240 MPa and superb weldability, this material is perfect for shaping intricate designs without sacrificing structural integrity. Grade 1 titanium is notably resistant to a variety of corrosive environments, including chlorides, seawater, and industrial chemicals, making it an excellent choice for both marine and chemical processing applications.
| Specifications | ASTM B381, ASME SB381 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | O | N | Fe | H | Ti | I |
| Min | – | – | – | – | – | 99.095 | – |
| max | 0.080 | 0.18 | 0.030 | 0.2 | 0.015 | 100 | 0.2 |
| Grades | Tensile KSI Min | Yield KSI Min/Max | % Elongation Min |
| Titanium Gr 1 | 35 | 25/45 | 24 |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Grade 1 | 3.7025 | R50250 |
Titanium Grade 1 forgings are commonly used in aerospace, chemical processing, marine, medical, and automotive industries due to their excellent corrosion resistance, lightweight, high strength, and biocompatibility properties.
Titanium Grade 1 forgings are made by heating titanium billets, then shaping them using compressive forces like hammering or pressing, followed by precision machining to achieve the desired specifications.
Open-die forging for Titanium Gr 1 involves compressing heated titanium between flat or contoured dies, allowing metal to deform freely, producing strong, customized components with excellent structural integrity.
These forgings find extensive use in sectors like chemical processing, desalination, marine engineering, medical equipment, and aerospace components. Typical applications include flanges, valve bodies, pipe fittings, and custom-shaped parts where corrosion resistance, biocompatibility, and strength-to-weight efficiency are essential. Their ability to perform reliably in harsh environments makes them a dependable and durable option for industries that require high-quality titanium forgings with outstanding formability and longevity.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
