Sahil Metals, based in Riyadh, Saudi Arabia, is a reliable manufacturer and supplier of top-notch **Titanium Grade 11 Forgings**. These forgings are designed to offer outstanding corrosion resistance and mechanical strength, making them perfect for demanding industrial settings. Crafted to meet international standards, they’re particularly suited for applications in chemical processing, marine environments, and power generation. Sahil Metals proudly caters to clients throughout Saudi Arabia and the Middle East, providing precision-forged components that can handle tough operating conditions.
Titanium Grade 11 Forgings are created from a commercially pure titanium alloy, with a small amount of palladium (0.12%–0.25%) added to boost their resistance to crevice corrosion and reduce acid damage. With mechanical properties akin to Grade 2—boasting a tensile strength of about 345 MPa—they deliver excellent ductility, weldability, and toughness. Grade 11 is dependable in environments with chlorides, acids, and other corrosive substances, ensuring it maintains its structural integrity over time.
| Specifications | ASTM B381, ASME SB381 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | N | O | H | Ti | Fe | Al | Pd |
| Titanium Gr 11 | 08 max | 03 max | 25 max | 015 max | Bal | 0.30 max | – | 12 – .25 |
| Grade | Tensile Strength min | Yield Strength (0.2 % Offset) | Elongation | Reduction of Area | ||
| ksi | Mpa | ksi | Mpa | min % | min % | |
| 11 | 35 | 240 | 25 | 170 | 24 | 30 |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 11 | 3.7225 | R52550 |
Yes, Titanium Gr 11 forgings are highly corrosion-resistant, especially to oxidizing environments and seawater. This makes them ideal for applications in industries like aerospace, marine, and chemical processing, ensuring long-lasting durability.
Titanium Gr 11 forgings are commonly used in industries such as aerospace, marine, chemical processing, medical, and power generation. Their strength, corrosion resistance, and high-performance capabilities make them ideal for demanding applications.
Yes, Titanium Gr 11 forgings can be customized for specific applications, offering tailored sizes, shapes, and properties to meet unique industry requirements, ensuring optimal performance and reliability in demanding environments.
These forgings find extensive use in heat exchangers, chemical tanks, flanges, pressure vessels, marine fittings, and desalination systems. Their ability to resist corrosion in both oxidizing and mildly reducing conditions makes them ideal for components in harsh chemical environments. Offering a durable, lightweight, and low-maintenance solution, these forgings guarantee reliable performance in high-demand industrial applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
