Khaleed Stainless, based in Riyadh, Saudi Arabia, has earned a solid reputation as a reliable manufacturer and supplier of specialty stainless steel products designed for tough industrial applications. One of their standout offerings is the **Stainless Steel XM19 Forgings**, which are celebrated for their remarkable blend of strength, corrosion resistance, and durability. These forgings are specifically engineered to thrive in high-stress environments, making them perfect for marine, chemical, and oil & gas industries. Khaleed Stainless is committed to ensuring that every forged product adheres to rigorous dimensional and quality standards, delivering high-performance components that you can count on in both structural and corrosive settings.
Stainless Steel XM19, often referred to as Nitronic® 50, is a nitrogen-strengthened austenitic stainless steel alloy that contains approximately 20–23.5% chromium, 11–13.5% nickel, 4–6% manganese, along with added nitrogen and molybdenum. It boasts nearly double the yield strength of 316 stainless steel while still offering excellent corrosion resistance. Its mechanical properties include a tensile strength of around 880 MPa and a yield strength ranging from 380 to 450 MPa. Notably, XM19 remains non-magnetic even after cold working and maintains outstanding toughness at both high and low temperatures, making it a dependable choice for precision forgings.
| Standard | ASTM A182, ASME SA182 |
| Specification | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs. |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs. |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs. |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni |
| SS XM19 | 0.06 max | 0.10 max | 0.1 max | – | 0.03 max | 20.50 – 23.50 | – | 11.50 – 13.50 |
| Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| ksi – 95 | ksi – 50 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS |
| SS XM19 | 1.3964 | S20910 |
The forging process for Stainless Steel XM19 typically takes several hours, depending on the size and complexity of the part. Heating, shaping, and cooling stages contribute to the overall duration.
The ideal temperature range for forging Stainless Steel XM19 is between 2100°F to 2200°F (1149°C to 1204°C). It's important to maintain proper cooling to avoid distortion or cracking.
Yes, Stainless Steel XM19 (a high-strength alloy) can be forged into custom shapes. It offers excellent formability, allowing manufacturers to create parts with specific dimensions and designs as needed.
Stainless Steel XM19 Forgings find extensive use in industries that demand both corrosion resistance and high mechanical strength. In marine settings, they are utilized for shafts, propeller components, and hardware that come into contact with seawater. In the oil & gas and chemical sectors, XM19 is the go-to material for valve bodies, pump shafts, and flange components that need to withstand stress and aggressive media. Additionally, it’s employed in food processing, pulp & paper, and aerospace applications. These forgings are designed to offer a long service life, reduced maintenance, and exceptional performance in high-load and high-corrosion environments.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
