Sahil Metals stands out as a top manufacturer and supplier located in Riyadh, Saudi Arabia, focusing on high-quality metal products designed to meet a variety of industrial needs. Known for its dedication to excellence, Sahil Metals provides an extensive selection of stainless steel forgings, including the robust Stainless Steel 304L Forgings. These forgings are meticulously crafted to adhere to strict standards, guaranteeing exceptional strength and resistance to corrosion. Utilizing cutting-edge technology and a team of skilled professionals, Sahil Metals caters to multiple sectors, delivering dependable, long-lasting solutions that foster innovation and enhance performance across industries in the region.
The Stainless Steel 304L forgings are primarily made up of iron, featuring 18-20% chromium and 8-12% nickel, along with a low carbon content (maximum 0.03%) to improve weldability and minimize carbide precipitation. This alloy is known for its outstanding corrosion resistance and toughness. In terms of mechanical properties, it typically boasts a tensile strength of 485 MPa, a yield strength of around 170 MPa, and an elongation of about 40%. The low carbon content enhances its resistance to sensitization, making it perfect for welded components that need to withstand harsh environments while maintaining durability and stability.
| Specifications | ASTM A182, ASME SA182 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 304L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.03 max | 18 – 20 | – | 8 – 13 | – |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 304L | 1.4306 / 1.4307 | S30403 | SUS 304L | 3304S11 | 03Х18Н11 | Z3CN18‐10 | X2CrNi18-9 / X2CrNi19-11 |
Post-forging operations for Stainless Steel 304L include heat treatment, machining, surface finishing, and testing to ensure optimal strength, dimension accuracy, and corrosion resistance.
To determine if Stainless Steel 304L forgings meet your needs, review material certifications, perform quality checks, and ensure they meet required mechanical properties and dimensional standards.
After Stainless Steel 304L forgings, slow cooling in air or controlled environments is recommended to prevent cracking and ensure uniform grain structure and mechanical properties.
Stainless Steel 304L forgings find widespread use in industries where strength and corrosion resistance are paramount. They are commonly utilized in chemical processing equipment, pressure vessels, heat exchangers, and piping systems. Their hygienic properties and rust resistance also make them a popular choice in food processing, pharmaceutical manufacturing, and marine applications. Furthermore, 304L forgings are employed in architectural structures and automotive parts where durability and weldability are crucial, making them a versatile option for demanding industrial applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
