Sahil Metals stands out as a top-notch manufacturer and supplier of Stainless Steel 316 Forgings right in Riyadh, Saudi Arabia. These forgings are celebrated for their remarkable corrosion resistance and strength, making them perfect for tough industrial applications. Crafted with care from high-quality stainless steel, SS 316 forgings excel in resisting chlorides, acids, and harsh marine environments. At Sahil Metals, we offer a variety of SS 316 forged components, including flanges, rings, and valve parts, all made to meet international standards. With a solid presence in the region, we proudly serve clients throughout Saudi Arabia and the Middle East, ensuring quality, consistency, and timely delivery.
Stainless Steel 316 Forgings are composed of 16–18% chromium, 10–14% nickel, and 2–3% molybdenum, which boosts their resistance to pitting and crevice corrosion. This alloy boasts a tensile strength of around 515–770 MPa and maintains excellent toughness, even in cryogenic conditions. In its annealed state, SS 316 is non-magnetic and offers great formability and weldability. These impressive mechanical and chemical properties make it a go-to choice for aggressive chemical environments, high-pressure systems, and marine applications where strength and resistance are essential.
| Specifications | ASTM A182, ASME SA182 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 316 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 11.00 – 14.00 | 67.845 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1399 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316 | 1.4401 / 1.4436 | S31600 | SUS 316 | 316S31 / 316S33 | – | Z7CND17‐11‐02 | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 |
Yes, Stainless Steel 316 forgings can be shaped into custom forms using precision forging techniques, allowing for a wide range of applications in various industries, including marine and chemical sectors.
The ideal temperature range for forging Stainless Steel 316 is between 2100°F to 2300°F (1149°C to 1260°C), ensuring optimal ductility and minimizing the risk of cracking.
The forging process for Stainless Steel 316 typically takes from a few minutes to several hours, depending on the part's complexity, size, and required finishing.
You’ll find Stainless Steel 316 Forgings widely used across various sectors, including chemical processing, pharmaceuticals, marine, oil & gas, and food industries. Their ability to handle corrosive media makes them ideal for pump components, valve bodies, pressure vessel parts, heat exchangers, and pipe fittings. In marine settings, they stand up to saltwater corrosion, while in industrial applications, they deliver durability under high-stress and corrosive conditions. SS 316 forgings promise a long service life, low maintenance, and high performance, even in the most challenging environments.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Sahil Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Riyadh, Saudi Arabia
