Sahil Metals is one of the prominent stainless steel manufacturers with graded steel in all kinds of qualities available in the market. The products from this company are delivered to countries and cities of local as well as international significance. Among the outstanding options available is the SS 431 Hollow Bar. They come in various sizes and forms, designed according to individual requirements. The most important advantage of Sahil Metals is the exceptional density and strength-to-weight ratio of their products. SS 431 grade has a density of 8 grams per cubic centimeter, much higher than other stainless steel grades available in the market. This high density ensures better quality and strength with abrasion resistance in stainless steel. Sahil Metals relies heavily on an inspection team for upholding the highest quality standard.
SS 431 Hollow Bar is a martensitic stainless steel that is both durable and resistant to corrosion. The composition contains nearly 16-18% chromium, 1.25-1.50% molybdenum, and 0.15-0.25% carbon, which provides very high tensile strength with resistance Machine with SS 431 580-750 MPa tensile strength, 415 MPa It has a hard up to 50- 55 HRC including yield strength, 12-15% elongation, Therefore it has good hardness and has a tendency to be suitable for high-stress applications. SS 431 has good resistance to oxidation; it is, therefore an excellent choice for industrial application.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A582, A276, A564, ASTM A484, 484M
Surface : hrap, hot rolled pickled or sand blasting finished, cold drawn, polished, hairline
Range : Range – 3.17mm to 350mm dia
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 431 | 0.20 | 17.00-15.00 | 1.00 | 2.50-1.25 | 0.040- | 0.030 | 1.00 |
| Element | Density | Electrical Resistivity | Modulus of Elasticity |
| SS 431 | 0.2800 lb/inch³ | 70° Ohms (circ mil./ft.) | 29.0 X 10^3 |
| Hollow Bar | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.49 | 1.60 |
| 18 | 0.62 | 2.02 |
| 20 | 0.76 | 2.49 |
| 22 | 0.92 | 3.02 |
| 25 | 1.19 | 3.90 |
| 28 | 1.49 | 4.89 |
| 28 | 1.49 | 4.89 |
| 30 | 1.71 | 5.61 |
| 32 | 1.95 | 6.38 |
| 36 | 2.46 | 8.08 |
| 38 | 2.74 | 9.00 |
| 40 | 3.04 | 9.97 |
| 45 | 3.85 | 12.62 |
| 50 | 4.75 | 12.62 |
| 56 | 8.96 | 19.55 |
| 60 | 6.84 | 22.44 |
| 65 | 8.03 | 26.34 |
| 70 | 9.31 | 30.54 |
| 75 | 10.69 | 35.06 |
| 80 | 12.16 | 39.89 |
| 90 | 15.39 | 50.49 |
| 100 | 19 | 62.34 |
Stainless Steel 431 Hollow Bars find their place in various industries that require high strength and moderate corrosion resistance. They’re commonly used in marine hardware, pump and valve components, shafts, spindles, and fasteners. Thanks to their outstanding mechanical strength, they are also ideal for aerospace fittings, automotive parts, and power generation equipment. Additionally, these bars are utilized in petrochemical processing, the paper and pulp industry, and construction sectors where durability and wear resistance are essential. Their precision and reliability make them a valued choice across these applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Sahil Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Riyadh, Saudi Arabia
