Sahil Metals, a top-notch manufacturer and supplier based in Riyadh, Saudi Arabia, has built a solid reputation for providing high-quality stainless steel products, particularly Stainless Steel 317L Square Bars/Rods. With a keen emphasis on precision, durability, and adherence to international standards, the company has become a trusted partner for various industries both in Saudi Arabia and beyond. The SS 317L Square Bars/Rods are highly valued for their exceptional corrosion resistance, toughness, and ease of fabrication. Sahil Metals prides itself on maintaining strict quality control, offering competitive prices, and ensuring timely deliveries, making it a go-to choice for sectors like construction, chemical, marine, and petrochemical.
These Stainless Steel 317L Square Bars/Rods are made up of chromium (18–20%), nickel (11–15%), and molybdenum (3–4%), featuring a low carbon content that helps reduce carbide precipitation during welding. This unique composition significantly boosts corrosion resistance, especially in harsh and chloride-heavy environments. On the mechanical side, SS 317L Square Bars/Rods boast a tensile strength of around 515 MPa, a yield strength of 205 MPa, and an elongation of about 35%. They are known for their excellent toughness, durability, and resistance to high-temperature scaling, making them ideal for demanding applications where mechanical reliability and corrosion resistance are crucial.
Stainless Steel 317L Square Bars Specification :
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A582, A276, A564, ASTM A484, 484M
Surface : hrap, hot rolled pickled or sand blasting finished, cold drawn, polished, hairline
Size : Tolerance: H8, H9, H10, H11, H12, H13K9, K10, K11, K12
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 317 | 0.03 max. | 18.0 – 20.0 | 2.00 max. | 11.0 – 15.0 | 0.045 max. | 0.03 max. | 0.75 max. |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi ” 75000, MPa ” 515 | Psi ” 30000, MPa ” 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 317 | 1.4438 | S31703 |
| SQUARES | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.62 | 2.05 |
| 18 | 0.79 | 2.59 |
| 20 | 0.76 | 2.49 |
| 22 | 1.18 | 3.87 |
| 25 | 1.52 | 5.00 |
| 28 | 1.91 | 6.27 |
| 30 | 2.19 | 7.20 |
| 32 | 2.50 | 8.19 |
| 36 | 3.16 | 10.37 |
| 38 | 3.52 | 11.55 |
| 40 | 3.90 | 12.80 |
| 45 | 4.94 | 16.20 |
| 50 | 6.10 | 20.00 |
| 56 | 7.65 | 25.08 |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
You’ll find Stainless Steel 317L Square Bars/Rods widely utilized in industries that require both corrosion resistance and structural integrity. They are commonly used in chemical and petrochemical plants, pulp and paper production, food processing equipment, textile dyeing machinery, and marine settings. Their ability to endure acidic and chloride conditions makes them perfect for applications like condensers, heat exchangers, and pollution control systems. Moreover, they are also employed in various fabrication and construction projects, as well as in pharmaceutical machinery. Thanks to their low carbon content and enhanced durability, SS 317L Square Bars/Rods deliver long-lasting performance even in the toughest and most demanding environments.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
