Sahil Metals, located in Riyadh, Saudi Arabia, has built a solid reputation as a reliable manufacturer and supplier of high-performance metal products, with a focus on advanced alloys tailored for tough industrial applications. Among their standout offerings are Inconel 617 bars and rods, which are celebrated for their remarkable strength, resistance to oxidation, and stability even at high temperatures. These bars and rods find their place in high-temperature settings like power generation, petrochemical, and aerospace industries. Sahil Metals is dedicated to providing top-notch materials with precision engineering, making them a dependable partner for customers in search of durable, high-performance metal solutions throughout the Middle East.
Inconel 617 is a nickel-chromium-cobalt-molybdenum alloy crafted for high-temperature strength and oxidation resistance. Its typical makeup includes about 52% nickel, 22% chromium, 12.5% cobalt, and 9% molybdenum, along with trace amounts of aluminum and carbon. This alloy boasts a tensile strength of roughly 690 MPa and a yield strength of around 330 MPa, showcasing excellent creep and rupture resistance up to 1100°C. It maintains mechanical stability in harsh thermal environments and offers good weldability. Inconel 617 is often utilized in solution-annealed and aged conditions to boost its structural and thermal performance.
| Standards | ASTM B166, ASME SB 166, AMS 5887 |
|---|---|
| Specifications | DIN, EN, ASTM, JIS, ASME, BS, AISI |
| 617 Inconel Round Bars size | Diameter: 3-~800mm |
| Inconel 617 Flat Bars size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Inconel 617 Angle Bars size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Inconel 617 Channel Bars | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Alloy 617 Rectangular Bars Section | 3.0 to 12.0mm thickness |
| Inconel 617 Billet Size | 1/2 to 495mm Diameter |
| Inconel 617 Rectangle Bar Size | 33 x 30mm to 295 x 1066mm |
| Inconel 617 Hex Bar size | 2-100mm A/F |
| Inconel 617 Hollow Bars | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Diameter | 20mm, 30mm, 50mm, 80mm, 100mm, 150mm, 200mm, 500mm |
| Length | 1m-12m or as required |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish | hot rolled annealed, peeled, Bright, hot-worked and cold-worked rod and bar, centreless ground, Centreless Ground and Black, Polish, Cold Rolled (CR), hot rolled ( R), smooth turned, Cold (bright) drawn, Grinding, slit rolled edge, Rough Turned. |
| Surface | Hot Rolled Pickled, Bright, Sand Blasting Finished, Cold Drawn, Hairline,Polished |
| Condition | Hardened & tempered, annealed |
| Technique | Cold Drawn, Hot Rolled, Forged Round Bars, Cold Rolled, Rod |
| Processing | Bars cutting to 650mm |
| Form | Rod, Round, Channel Bars, T-Bars, Flat Bars, Precision Ground Bars, Blocks, Square, Round Rod, Triangle, Hollow, Rectangle, Threaded, Hex (A/F), Profiles, Half Round Bars, Ingot, Billet, I/H Bars, Forging etc. |
| STANDARD | WERKSTOFF NR. | UNS |
| Inconel 617 | 2.4663 | N06617 |
| Grade | Ni | Cr | Fe | C | Mn | S | Mo | Si | Co |
| Inconel 617 | 48.85 – 62 | 20 – 24.0 | Balance | ≤ 0.15 | ≤ 1 | – | 8 – 10 | ≤ 1 | 10-15 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.3g/cm³ | 1363°C | ≥ 485 MPa | ≥ 275 MPa | 25 % |
Yes, Inconel 617 Bars/Rods are designed to perform exceptionally well in high-temperature environments up to 980°C.
Yes, they can be tailored in terms of size, dimensions, and specifications to meet specific industrial requirements.
Yes, we provide bars and rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@sahilmetals.com
Inconel 617 bars and rods are widely used in high-temperature and high-stress environments, including gas turbines, heat exchangers, petrochemical processing units, and nuclear reactors. Their ability to withstand oxidation and carburization at elevated temperatures makes them perfect for furnace components and combustion systems. These bars and rods are also popular in aerospace applications, especially in engine components that face extreme thermal cycling. Their exceptional strength, corrosion resistance, and thermal stability guarantee long-lasting reliability and performance, even in the most demanding industrial conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Sahil Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Riyadh, Saudi Arabia
