Ashraf Nickel Alloys is a well-respected manufacturer and supplier based in Riyadh, Saudi Arabia, known for providing top-notch **Incoloy 925 Forgings** that meet the needs of demanding industrial sectors. These forgings are celebrated for their outstanding corrosion resistance, impressive tensile strength, and durability, making them reliable choices for tough environments like marine, chemical, and oil & gas industries. At Ashraf Nickel Alloys, they prioritize precise manufacturing and rigorous quality control, ensuring that their **Incoloy 925 Forgings** deliver exceptional mechanical properties, longevity, and performance, which is why they are a go-to option for industries that require strong and trustworthy forged components.
The **Incoloy 925 Forgings** are primarily made up of nickel, iron, and chromium, with notable additions of copper, molybdenum, and titanium. This unique blend boosts their resistance to pitting, crevice corrosion, and stress-corrosion cracking, especially in environments with chlorides. On the mechanical side, they boast a tensile strength of around 760 MPa and a yield strength of about 450 MPa, along with good elongation and toughness. Heat treatment further enhances their strength and hardness. These forgings maintain stability even under high pressure and harsh operating conditions, making them ideal for both high-stress and corrosive service applications.
Specifications ASTM B637 / ASME SB637
Flat bar blocks up to 27″ width and 15,000 lbs.
Cylinders and sleeves up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts up to 144″ maximum length and 20,000 lbs.
| Grade | Ni% | Cr% | Fe% | Mo% | Cu% | Ti% | Al% | Mn% | Si% | Nb% | C% | S% |
| Incoloy 925 | 42.0-46.0 | 19.5-22.5 | Min 22 | 2.5-3.5 | 1.5-3.0 | 1.9-2.4 | 0.1-0.5 | Max 1.0 | Max 0.5 | Max 0.5 | Max 0.03 | Max 0.03 |
| UNS | Heat Treatment | Tensile Strength, min, psi (MPa) | Yield Strength (0.2 % offset), min, psi (MPa) | Elongation in 2 in. (50 mm) or 4D, min, % | Reduction of Area, min, % | Brinell or (Rockwell C) Hardness |
| ASTM B637 UNS N09925 | solution + precipitation harden | 140 000 (965) | 105 000 (724) / 110 000 (758) | 18 | 25 | 346 max (38, Rc max) |
| STANDARD | UNS | WNR. |
| Alloy 925 | N09925 | – |
The ideal temperature range for forging Incoloy 925 is between 1,800°F (982°C) and 2,200°F (1,204°C). Forging should be done within this range to achieve optimal material properties and avoid overheating.
Incoloy 925 forgings require minimal maintenance due to their excellent corrosion resistance. Regular inspection for signs of wear, cracks, or environmental damage is recommended to ensure long-term performance.
Incoloy 925 forgings have limited high-temperature strength beyond 1,600°F (871°C) and may suffer from reduced ductility in extreme conditions. They also exhibit moderate resistance to pitting and crevice corrosion in highly aggressive environments.
You’ll find **Incoloy 925 Forgings** commonly used in oil and gas production equipment, such as valves, tubing, packers, and hangers, thanks to their strength and resistance to sour gas environments. In the marine sector, they’re utilized in equipment exposed to seawater, fasteners, and shafts. The chemical and petrochemical industries rely on them for processing equipment, piping systems, and heat exchangers where resistance to aggressive chemicals is crucial. Their high strength and corrosion resistance also make them suitable for aerospace, power generation, and structural applications where performance and reliability are key.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
