Incoloy 800H Forgings

Sahil Metals, located in Riyadh, Saudi Arabia, stands out as a trusted manufacturer and supplier of high-performance alloy products designed for tough high-temperature applications. Among their top-tier offerings are **Incoloy 800H Forgings**, celebrated for their remarkable strength, resistance to creep, and ability to withstand oxidation at elevated temperatures. This alloy is specifically crafted for high-heat environments where long-lasting structural stability and corrosion resistance are essential. Sahil Metals provides 800H forgings that meet international standards, catering to industries throughout Saudi Arabia and the GCC.

ASTM B564 Incoloy Alloy 800H Forgings Price in Saudi Arabia, Stockist of Incoloy UNS N08810 Forgings in Al Jubail, Incoloy Alloy 800H Closed Die Forging Price List in Riyadh, Incoloy UNS N08810 Open Die Forging Weight Chart, Incoloy UNS N08810 Closed Die Hammer Forging Supplier in Saudi Arabia, Incoloy 800H Press Forging Manufacturer in Ras Al Khair,Incoloy 800H Compression Forging Jeddah, Incoloy UNS N08810 Impression Die Forging Size Chart, Incoloy 1.4958 Upset Forging Dealer in Jeddah

Incoloy 800H Hot Forging

Incoloy 800H Open Die Forging

Incoloy 800H Closed Die Forging

What is Incoloy 800H Forgings?

**Incoloy 800H Forgings** primarily consist of nickel (30–35%), chromium (19–23%), and iron (the balance), with carefully controlled amounts of carbon, aluminum, and titanium. In comparison to standard Incoloy 800, the 800H grade boasts a higher carbon content and a controlled grain size, which significantly boosts its creep and rupture strength at high temperatures. These forgings are reliable at temperatures reaching up to 1100°C (2010°F), offering excellent resistance to oxidation, carburization, and sulfidation. They also maintain strong structural integrity and metallurgical stability over extended service periods.

Incoloy UNS N08810 Impression Die Forging Distributor in Saudi Arabia, Incoloy UNS N08810 Cold Forging Stockist Dammam, UNS N08810 Incoloy 800H Open Die Forging Exporter in Saudi Arabia, Incoloy UNS N08810 Compression Forging Price in Dammam, 1.4958 Incoloy Upset Forging Dimensions, UNS N08810 Incoloy Forgings Supplier in Saudi Arabia, Incoloy 800H Open Die Hammer Forging Supplier in Al Jubail, Incoloy N08810 Press Forgings in Ras Al Khair, Incoloy DIN 1.4958 Open Die Hammer Forging Stockist in Riyadh, ASTM A182 Incoloy N08810 Forging Price List Ras Al Khair

Incoloy 800H Forgings Specification

Specifications ASTM B564 / ASME SB564, AMS 5766

Flat bar blocks up to 27″ width and 15,000 lbs.

Cylinders and sleeves up to 50″ maximum O.D. and 65″ maximum length

Discs and hubs up to 50″ diameter and 20,000 lbs.

Rolled, hand forged or mandrel forged rings up to 84″ maximum O.D. and 40″ maximum length

Rounds, shafts and step shafts up to 144″ maximum length and 20,000 lbs.

Chemical Compositions of Incoloy 800H Forgings

Grade	Ni	Fe	Cr	Cu	Ti	Al	C	Mn	S	Si
Alloy 800H	30.0-35.0	39.5 min	19.0-23.0	.75 max	.15-.60	.15-.60	.05-.10 max	1.5 max	.015 max	1.0 max

You Need Our Support, to Have Any Projects?

Test Certificate

Why Sahil Metals?

Packaging

Incoloy 800H Forgings Mechanical Properties

Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
7.94 g/cm3	1350-1400 ℃	Psi – 75,000 , MPa -520	Psi – 30,000 , MPa – 205	30 – 35 %

Incoloy 800H Forgings Physical Properties

Density	0.287 lb/in3 / 7.94 g/cm3
Melting Point	2475 – 2525 °F/ 1357 – 1385 °C
Specific Heat @ 70°F	0.11 Btu/lb•°F
Permeability @ 70°F Annealed	1.014 (200 Oersted)
Curie Temperature	-115 °C/ -175 °F
Elastic Modulus	28.50 X 106 psi
Electrical Resistivity @ 70°F	595 ohm•circ mil/ft
Annealling Incoloy 800	983 – 1038 °C / 1800 – 1900 °F
Annealling Incoloy 800H / Ht	1147 – 1177°C / 2100 – 2150 °F
Quench	Rapid Air / Water

Incoloy 800H Forgings Equivalent Grades

STANDARD	UNS	WNR.	AFNOR	EN	JIS	BS	GOST	OR
Incoloy 800H	N08810	1.4958	Z8NC32-21	X10NiCrAlTi32-20	NCF 800H	NA 15(H)	ЭИ670	XH32T

Modern Equipments

Expert Engineers

Well Maintained

Efficient Factories

Incoloy 800H Forgings Types

800H Incoloy Open Die Forging Stockist in Al Jubail, ASTM B564 Incoloy 800H Forgings Supplier in Saudi Arabia, Incoloy Alloy 1.4958 Compression Forging Size Chart, ASME SB564 Incoloy N08810 Hot Forging Exporter in Jeddah, Incoloy 800H Forgings Manufacturer in Dammam, N08810 Incoloy Industrial Forgings Distributor Exporter in Saudi Arabia, Incoloy UNS N08810 Seamless Rolled Forging Supplier in Al Jubail, UNS N08810 Incoloy Alloy Cold Forging Size Chart

Frequently Asked Questions (FAQ)

What Temperature Range is Ideal For forging Incoloy 800H?

The ideal temperature range for forging Incoloy 800H is between 2100°F and 2250°F (1149°C to 1232°C). This range ensures optimal workability and preserves the material’s mechanical properties.

What Post-Forging Operations Are Necessary for Incoloy 800H?

Post-forging operations for Incoloy 800H typically include annealing to relieve stress and enhance ductility, followed by heat treatment to achieve desired mechanical properties. Surface cleaning and inspection for defects are also essential to ensure quality.

How Can I Determine If Incoloy 800H Forgings Meet My Specific Needs?

To determine if Incoloy 800H Forgings meet your specific needs, review material specifications, including composition and mechanical properties, and consult with suppliers for customized testing or performance data. Additionally, consider your application's temperature, corrosion, and mechanical requirements.

Incoloy 800H Forgings Uses

**Incoloy 800H Forgings** find extensive use in heat exchangers, reformer outlet manifolds, furnace components, pressure vessels, and petrochemical processing equipment. Their outstanding high-temperature characteristics make them perfect for applications in power plants, chemical industries, and refineries, especially in scenarios involving thermal cycling and exposure to harsh environments. With their blend of strength, durability, and corrosion resistance, 800H forgings guarantee dependable performance and a long service life in critical high-temperature systems.

Our Products

Other Products

Other Material

If You Are Looking To Buy High Quality

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
