Sahil Metals, based in Riyadh, Saudi Arabia, stands out as a leading manufacturer and supplier of top-notch metal products, including Copper Nickel 95/5 Bars and Rods. Known for their commitment to quality, precision, and timely delivery, Sahil Metals caters to essential industries like marine, plumbing, HVAC, and power generation. Their Copper Nickel 95/5 Bars and Rods are crafted from high-grade raw materials and cutting-edge processes, ensuring remarkable corrosion resistance and workability. With a strong focus on meeting international standards, Sahil Metals provides reliable solutions designed for durability in tough environments throughout Saudi Arabia and the broader Middle East.
These Copper Nickel 95/5 Bars and Rods consist of 95% copper and 5% nickel, along with small amounts of iron and manganese to enhance strength and corrosion resistance. They boast impressive mechanical properties, featuring a tensile strength of about 250–350 MPa and a yield strength ranging from 70–120 MPa. With excellent ductility, they can elongate between 30–40%, and they show outstanding resistance to corrosion in both fresh and saltwater settings. The alloy’s ease of fabrication, compatibility with welding, and thermal stability make it a perfect choice for low- to moderate-pressure applications in marine and industrial systems.
| Standards | ASTM B151 / ASME SB151 |
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI all International Standards |
| Diameter | Outside Diameter in the range of 4mm to 500mm |
| Width | 1m to 48″ |
| Hex Bars | 18mm – 57mm (11/16″ to 2-3/4″) |
| Square Bars | 18mm – 47mm (11/16″ to 1-3/4″) |
| Flat Bars | 1/2” to 10” in the thickness range of 2mm to 150mm |
| Wire Length | Max 12000 mm |
| Wire Diameter | 5.5 – 400 mm |
| Length | 1 to 6 Meters, Custom Cut Lengths |
| Types | Round, Square, Hex (A/F), Flat, Square, Rectangle, Billet, Ingot, Forging, Wire Bobbin, Wire Spool, Wire Rope, Spring Wires, Welding Wire, Coiled Wire Etc. |
| STANDARD | UNS | WERKSTOFF NR. |
| Cu-Ni 95/5 | C70400 | – |
Melting Point – Liquidus°F |
2050 |
Densitylb/cu in. at 68°F |
0.323 |
Specific Gravity |
8.94 |
Electrical Conductivity% IACS at 68°F |
14 |
Thermal ConductivityBtu/ sq ft/ ft hr/ °F at 68°F |
37 |
Coefficient of Thermal Expansion 68-57210?6 per °F (68 – 572°F) |
9.7 |
Specific Heat CapacityBtu/ lb /°F at 68°F |
0.09 |
Modulus of Elasticity in Tensionksi |
17000 |
Modulus of Rigidityksi |
6400 |
Yes, Copper-nickel 95/5 bars and rods are suitable for hygienic and sanitary applications due to their antimicrobial properties, corrosion resistance, and non-toxic nature, making them ideal for water and food-related systems.
Yes, Copper-nickel 95/5 bars and rods can be recycled after use. Their high recyclability allows them to be reprocessed without significant loss of properties, promoting sustainability and resource efficiency.
Yes, Copper-nickel 95/5 bars and rods are suitable for potable water applications due to their excellent corrosion resistance, biofouling resistance, and durability, ensuring safe and long-lasting performance in water systems.
You’ll find Copper Nickel 95/5 Bars and Rods commonly used in marine hardware, plumbing systems, heat exchanger tubes, and condenser components, thanks to their exceptional resistance to corrosion and biofouling. Their lower nickel content makes them a more budget-friendly option while still providing the durability needed for non-aggressive marine and industrial environments. They’re also utilized in shipbuilding, HVAC systems, and water distribution networks. With great thermal conductivity and formability, Copper Nickel 95/5 is perfect for applications that require resistance to moisture, moderate mechanical stress, and a long service life in both industrial and commercial settings.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
