Copper Nickel 90/10 Bars and Rods

Sahil Metals, a well-respected manufacturer and supplier located in Riyadh, Saudi Arabia, specializes in top-notch metal products, particularly Copper Nickel 90/10 Bars and Rods. They’re known for their precision-engineered solutions that serve vital industries like marine, petrochemical, and power generation. The Copper Nickel 90/10 Bars and Rods from Sahil Metals are made with high-quality raw materials and cutting-edge manufacturing techniques, ensuring they boast excellent corrosion resistance, mechanical strength, and long-lasting durability. With a strong commitment to international standards and customer satisfaction, Sahil Metals is a trusted partner for all high-performance metal needs throughout the Middle East.

Cupro Nickel 90/10 Bars Exporter in Dammam, Cupro Nickel 90/10 Square Bar Stockist in Riyadh, DIN 2.0872 Hex Bar Supplier in Saudi Arabia, ASME SB111 Cupro Nickel 90/10 Rectangular Rod Distributor in Saudi Arabia, Copper Nickel 90/10 Hex Rod Stockist in Jeddah ,Cupro Nickel 90/10 Square Rod Price in Dammam, Cu-Ni 90/10 Bars in Saudi Arabia, UNS C70600 Forged Bar Manufacturer in Riyadh, Cu-Ni 90/10 Polish Flat Bar Supplier in Saudi Arabia, 90/10 CuNi Cold Drawn Round bar Supplier in United kingdom

Copper Nickel 90/10 Cold Drawn Bars

Cu-Ni 90/10 Bright Rods

90/10 Cu-Ni Threaded Rods

These Copper Nickel 90/10 Bars and Rods consist of about 90% copper and 10% nickel, with a touch of iron and manganese added to enhance their strength and resistance to corrosion. They showcase impressive mechanical properties, including a tensile strength ranging from 300 to 450 MPa, a yield strength of around 100 to 150 MPa, and an elongation of 30 to 35%. This alloy is particularly renowned for its exceptional resistance to seawater corrosion, stress cracking, and erosion. Its mechanical stability and durability in harsh environments make it perfect for high-performance applications in both marine and industrial settings.

Cupro Nickel UNS C70600 Bright Bar in Al Jubail, ASME SB 111 Cupro Nickel 90/10 Flat Bar Supplier in Saudi Arabia, 90/10 Cu-Ni Flat Bar Price List in Riyadh, Stockist of Copper Nickel 90/10 Square Bar in Al Jubail, Cu-Ni 90/10 Bars and Rods Exporter in Ras Al Khair, Cu-Ni 90/10 Rectangular Bar Exporter in Saudi Arabia, Cu-Ni 90/10 Hot Rolled Round Bar Exporter in Jeddah, Cu-Ni 90/10 Cold Drawn Bars Manufacturer in Dammam, Cu-Ni 90/10 Black Bar Stockists in Saudi Arabia, High Quality Copper Nickel 90/10 Rods Dealer in Ras Al Khair

Copper Nickel 90/10 Bars and Rods Specification

Standard	ASTM B111, ASME SB111
Round Bar Size	3mm~ 800mm
Square Bar Size	4mm* 4mm ~100mm* 100mm
Flat Bar Size	2mm ~ 100mm
Hex Bar Size	2mm ~ 100mm
Angle Size	3mm* 20mm* 20mm~ 12mm* 100mm* 100mm
Thickness	50 mm to 6000 mm Long
Length	1 To 6 Meters, Custom Cut Length
Form	Round, Square, Hex(A/F), Rectangle, Billet, Ingot, Forging Etc

Chemical Compositions of Copper Nickel 90/10 Bars and Rods

Grade	Cu	Mn	Pb	Ni	Fe	Zn
Cu-Ni 90-10	88.6 min	1.0 max	.05 max	9-11 max	1.8 max	1 max

Copper Nickel 90/10 Bars and Rods Mechanical Properties

Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
8.89 g/cm3	2260 F	50000 psi	20000 psi	30 %

Copper Nickel 90/10 Bars and Rods Equivalent Grades

STANDARD	WERKSTOFF NR.	UNS
Copper Nickel 90 / 10	2.0872	C70600

You Need Our Support, to Have Any Projects?

Test Certificate

Why Sahil Metals?

Packaging

Copper Nickel 90/10 Bars and Rods Sizes

Metric		US Rods		ASTM/ Canadian		Japanese
Rods Size	Diam. (mm)	Rods Size	Diam. (Inch)	Rods Size	Diam. (mm2)	Rods Size	Diam. (mm)
5	5	#2	0.250	10M	100	6	6
5.5	5.5	#3	0.375	15M	200	10	10
6	6	#4	0.500	20M	300	13	13
7	7	#5	0.600	25M	500	16	16
8	8	#6	0.750	30M	700	19	19
9	9	#7	0.875	35M	1000	22	22
10	10	#8	1.000	45M	1500	25	25
11	11	#9	1.125	55M	2500	29	29
12	12	#10	1.250			32	32
14	14	#11	1.375			35	35
16	16	#12	1.500			38	38
18	18	#13	1.600			41	41
20	20	#14	1.750			44	44
22	22	#15	1.875			48	48
25	25	#16	2.000			51	51
28	28	#18	2.250			57	57
32	32
36	36
40	40
44	44
50	50

Weight Chart of Copper Nickel 90/10 Bars and Rods

Size	Kgs / Foot	Kgs / Mtr	Size	Kgs / Foot	Kgs / Mtr	Size	Kgs / Foot	Kgs / Mtr
3mm	0.017	0.055	20mm	0.753	2.470	3″	10.900	35.762
1/8″	0.019	0.062	22mm	0.908	2.979	3-1/4″	12.800	41.996
5/32″	0.029	0.095	7/8″	0.926	3.038	3-1/2″	14.850	48.772
4mm	0.030	0.098	24mm	1.080	3.543	3-3/4″	17.001	55.780
3/16″	0.043	0.141	25mm	1.180	3.871	4″	19.306	63.340
5mm	0.047	0.154	1″	1.210	3.970	4-1/4″	21.908	72.249
7/32″	0.058	0.190	26mm	1.271	4.170	4-1/2″	24.4487	80.340
6mm	0.068	0.223	27mm	1.368	4.490	4-3/4″	27.366	90.249
1/4″	0.076	0.249	1-1/8″	1.534	5.033	5″	30.461	99.940
7mm	0.091	0.298	30mm	1.691	5.548	5-1/2″	36.690	121.000
5/16″	0.118	0.387	1-1/4″	1.924	6.349	6″	43.860	143.900
8mm	0.120	0.398	32mm	1.894	6.314	6-1/2″	51.093	167.630
9mm	0.152	0.498	1-3/8″	2.303	7.550	7″	59.432	196.000
3/8″	0.170	0.557	35mm	2.390	7.553	7-1/2″	68.226	225.000
10mm	0.189	0.620	36mm	2.438	7.999	8″	77.586	254.55
11mm	0.228	0.748	38mm	2.792	8.903	10″	121.048	397.140
7/16″	0.232	0.761	1-1/2″	2.715	8.951
12mm	0.271	0.889	40mm	3.009	9.872
1/2″	0.303	0.994	1-5/8″	3.200	10.449
13mm	0.318	1.043	1-3/4″	3.712	12.179
14mm	0.368	1.207	45mm	3.807	12.555
9/16″	0.383	1.256	1-7/8″	4.260	13.977
15mm	0.424	1.391	48mm	4.330	14.205
5/8″	0.473	1.551	50mm	4.698	15.414
16mm	0.481	1.578	2″	4.848	15.906
17mm	0.543	1.791	2-1/8″	5.475	17.963
11/16″	0.573	1.880	2-1/4″	6.135	20.128
18mm	0.610	2.001	60mm	6.768	22.205
3/4″	0.682	2.237	2-3/8″	6.838	22.435
			2-1/2″	7.576	24.856
			2-5/8″	8.354	27.409
			2-3/4″	9.169	30.083

Modern Equipments

Expert Engineers

Well Maintained

Efficient Factories

Copper Nickel 90/10 Bars and Rods Types

Cu-Ni DIN 2.0872 Hex Bar Dealer in Riyadh, AISI 90/10 Hex Bar Supplier in Al Jubail, 90/10 Copper Nickel Hex Bar Manufacturer in Ras Al Khair, ASTM B151 90/10 Copper Nickel Forged Rods Supplier in Jeddah, Cupronickel 90/10 Rectangle Bar Size Chart, Copper Nickel 90/10 Solid Rod Price in Dammam, UNS C70600 90/10 Copper Nickel Square Bars and Rods Supplier in Saudi Arabia, ASME SB151 90/10 Cu Ni Half Round Bars Stockist in Ras Al Khair, Cupronickel 2.0872 Threaded Bar Supplier in Riyadh

Frequently Asked Questions (FAQ)

How Are Copper Nickel 90/10 Bars and Rods Sized?

Copper Nickel 90/10 bars and rods are sized by diameter, length, and cross-sectional dimensions, typically measured in millimeters or inches, conforming to ASTM, ASME, or international standards.

What Are The Considerations For Installing Copper Nickel 90/10 Bars and Rods?

Considerations for installing Copper Nickel 90/10 bars and rods include proper alignment, avoiding contamination, ensuring corrosion resistance in marine environments, and using compatible tools and fittings for secure connections.

Are Copper Nickel 90/10 Bars and Rods Suitable For Hygienic And Sanitary Applications?

Yes, Copper Nickel 90/10 bars and rods are suitable for hygienic and sanitary applications due to their corrosion resistance, antimicrobial properties, and ability to withstand harsh cleaning processes, ensuring cleanliness and durability.

Copper Nickel 90/10 Bars and Rods Uses

In marine engineering, Copper Nickel 90/10 Bars and Rods are frequently utilized for seawater piping, condenser tubes, pump shafts, and valve components, thanks to their outstanding corrosion and biofouling resistance. They also find applications in offshore oil rigs, shipbuilding, and desalination plants. Moreover, these bars are ideal for heat exchangers, power plants, and chemical processing systems, where strength, conductivity, and longevity are crucial. Their versatility and ability to endure extreme conditions make them perfect for both structural and fluid-handling applications.
