Sahil Metals, located in Riyadh, Saudi Arabia, is a reliable manufacturer and supplier of high-performance **Titanium Grade 6 Bars/Rods**. We cater to industries that require exceptional strength, corrosion resistance, and thermal stability. Renowned for our commitment to quality, Sahil Metals ensures that all our titanium bars adhere to rigorous international standards. While Titanium Grade 6 may not be as common, it’s a highly sought-after alloy for specialized applications. With a strong emphasis on precision, quality, and reliability, we proudly serve clients throughout Saudi Arabia and the Middle East with cutting-edge titanium solutions.
Our Titanium Grade 6 Bars/Rods are crafted with 5% aluminum and 2.5% tin, classifying them as an alpha-phase titanium alloy. This unique blend offers a mix of moderate strength, outstanding oxidation resistance, and good weldability. Grade 6 boasts a tensile strength of around 780 MPa and performs admirably in high-temperature settings. It retains its structural integrity under heat and exhibits excellent corrosion resistance in both oxidizing and marine environments, making it perfect for structural and high-temperature applications.
| Standards : | ASTM B348, B863 / ASME SB348, SB863 |
| Dimensions : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Wire : | Thickness starting from 0.05mm |
| Round bar size : | Diameter: 3-~800mm |
| Hex Bar size : | 2-100mm A/F |
| Flat bar size : | Thickness: 2 -100mm / Width: 10 to 500mm |
| Square bar size : | 4 to 100mm |
| Rectangular Bars Size : | 33 x 30mm to 295 x 1066mm |
| Hollow Bar : | 32mm OD x 16mm ID to 250mm OD x 200mm ID |
| Tolerance : | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish : | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr 6 | 3.7114 | R54520 |
| Grade | C | Fe | N | Ti | H | O | Al | Sn |
| Titanium Gr. 6 | .08 max | 0.50 max | .05 max | Balance | .0175 – .020 | .20 max | 4.0 – 6.0 | 2.0 – 3.0 |
| Element | Min.Tensile(KSI) | Min.Yield(KSI) | Hardness | Tensile Modulus | Poisson’s Ratio |
| Ti Grade 6 | 50 | 40 | 14.9 | 103 GPa | 0.34-0.10 |
| Type | SIZES (mm) | SIZES (Inches) | ISO Tolerance |
|---|---|---|---|
| Cold Drawn and Ground | 10.00 – 75.00 | 5/6″ – 2.50″ | h8-h9-h10-h11 |
| Peeled and Polished | 40.00 – 150.00 | 1.50″ – 6.00″ | h11, h11-DIN 1013 |
| Peeled and Ground | 20.00 – 50.00 | 3/4″ – 2.00″ | h9-h10-h11 |
| Cold Drawn and Polish | 3.00 – 75.00 | 1/8″ – 3.00″ | h8-h9-h10-h11 |
Titanium Grade 6 Bars Standard lengths of 2000 mm up to 6000 mm. Cut to size on request (tolerance +2/-0 mm).
| 5.0 | 45.0 |
| 6.0 | 50.0 |
| 7.0 | 55.0 |
| 8.0 | 60.0 |
| 9.0 | 65.0 |
| 10.0 | 70.0 |
| 12.0 | 75.0 |
| 16.0 | 80.0 |
| 20.0 | 90.0 |
| 25.0 | 100.0 |
| 30.0 | 130.0 |
| 35.0 | 160.0 |
| 40.0 | 200.0 |
Yes, we provide bars and rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@sahilmetals.com
Titanium Grade 6 Bars and Rods provide excellent strength-to-weight ratio, outstanding corrosion resistance, high-temperature stability, and good formability, making them ideal for high-performance applications.
Titanium Grade 6 Bars and Rods offer superior strength, corrosion resistance, and weldability, along with excellent performance in high-temperature and aggressive environments, making them suitable for critical industrial applications.
You’ll find Titanium Grade 6 Bars/Rods in aerospace components, heat exchangers, marine hardware, and power generation systems where high strength and thermal stability are essential. This alloy is especially prized in situations that involve prolonged exposure to high temperatures and corrosive conditions. Its resistance to oxidation and stress makes it an ideal choice for jet engines, airframes, and chemical processing systems. Although it’s not as widely used as other titanium grades, Grade 6 provides a unique blend of performance features for demanding, specialized applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
