Khaleed Stainless, located in Riyadh, Saudi Arabia, stands out as a top manufacturer and supplier of stainless steel products that resist corrosion. One of their standout offerings is the **Stainless Steel 904L Round Bars and Rods**, which are celebrated for their remarkable performance in extremely corrosive settings. These bars are crafted to exacting standards and come in a variety of diameters and finishes. Industries such as chemical processing, marine, oil & gas, and pharmaceuticals trust Khaleed Stainless for their 904L round bars, which blend strength, durability, and long-lasting corrosion resistance, even in the toughest conditions.
The Stainless Steel 904L Round Bars and Rods are made from a low-carbon, high-alloy austenitic stainless steel that contains about 25% nickel, 20% chromium, 4.5% molybdenum, and a touch of copper. This unique chemical makeup provides exceptional resistance to strong acids, pitting, and crevice corrosion. Typically, these bars boast a tensile strength ranging from 490 to 710 MPa and a yield strength of around 220 MPa. 904L is known for its excellent toughness, formability, and weldability. It remains non-magnetic when annealed and is particularly effective in environments rich in chlorides or acids, where standard stainless steels might struggle.
| Standards | ASTM / ASME |
| Designation | B 649, SB 649 |
| Grade | 904L Round Bars and Rods 904L Round Bars and Rods: ASTM B 649, ASME SB 649 |
EN/DIN | 1.4539 X1NiCrMoCu25-20-5 |
|---|---|
AFNOR | Z2CNDU25.20 |
UNS | N08904 |
AISI | 904L / F904L |
BS | 904S13 |
SS | 2562 |
OTHER | ASTM A182 ASTM A262 ASTM A479 ASTM B649 / ASME SB649 DIN 17440 EN10088-3 EN10272 NACE MR01-75 / ISO 15156 SEW 400-VdTÜV421 |
BRANDS | URANUS B6™ VLX904™ AL-904L™ CRONIFER 1925™ 2RK65™ |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Cu |
|---|---|---|---|---|---|---|---|---|---|
| SS 904L | 0.020 max | 2 max | 1 max | 0.040 max | 0.030 max | 19.0-23.0 | 4.0-5.0 max | 23.00 – 28.00 | 1.0-2.0 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 7.95 g/cm3 | 1350 °C (2460 °F) | Psi – 71000 , MPa – 490 | Psi – 32000 , MPa – 220 | 35% |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | KS | AFNOR | EN |
|---|---|---|---|---|---|---|---|
| SS 904L | 1.4539 | N08904 | SUS 904L | 904S13 | STS 317J5L | Z2 NCDU 25-20 | X1NiCrMoCu25-20-5 |
Type | SIZES (mm) | SIZES (Inches) | ISO Tolerance |
|---|---|---|---|
Cold Drawn and Polish | 3.00 – 75.00 | 1/8″ – 3.00″ | h8-h9-h10-h11 |
Cold Drawn and Ground | 10.00 – 75.00 | 5/6″ – 2.50″ | h8-h9-h10-h11 |
Peeled and Polished | 40.00 – 150.00 | 1.50″ – 6.00″ | h11, h11-DIN 1013 |
Peeled and Ground | 20.00 – 50.00 | 3/4″ – 2.00″ | h9-h10-h11 |
Cut to size on request (tolerance +2/-0 mm). Standard lengths of 904L Stainless Steel Bars 2000 mm up to 6000 mm available
5.0 | 45.0 |
6.0 | 50.0 |
7.0 | 55.0 |
8.0 | 60.0 |
9.0 | 65.0 |
10.0 | 70.0 |
12.0 | 75.0 |
16.0 | 80.0 |
20.0 | 90.0 |
25.0 | 100.0 |
30.0 | 130.0 |
35.0 | 160.0 |
40.0 | 904L.0 |
Yes, Stainless Steel 904L Round Bars/Rod can be easily welded, machined, and fabricated, offering excellent work ability due to its high nickel and chromium content, ensuring durability and resistance to corrosion.
Yes, Stainless Steel 904L Round Bars/Rod can be used at high temperatures, typically up to 1000°F (537°C), maintaining excellent corrosion resistance and strength in elevated thermal environments.
Yes, Stainless Steel 904L Round Bars/Rod can be fully recycled without losing quality. Stainless steel is highly recyclable, making it an eco-friendly material for various applications.
Stainless Steel 904L Round Bars and Rods find their place in industries where top-notch corrosion resistance is a must. In chemical and petrochemical plants, they are utilized in equipment that comes into contact with sulfuric, phosphoric, and acetic acids. The marine industry appreciates them for their use in saltwater systems, including shafts and fittings. In the pharmaceutical and food industries, they serve in hygienic and non-reactive processing equipment. These bars are also employed in pollution control systems, heat exchangers, and pressure vessels, providing a long service life, low maintenance, and resilience against extreme environmental conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
