Sahil Metals, based in Riyadh, Saudi Arabia, is your go-to source for high-quality **Super Duplex Steel S32760 Forgings** that are designed to excel in tough, corrosive, and high-pressure settings. We take pride in producing forgings that adhere to strict international standards, ensuring they deliver strength, corrosion resistance, and long-lasting durability. Serving various industries throughout Saudi Arabia and the Middle East, Sahil Metals specializes in precision-forged components that are essential for offshore, marine, and chemical processing applications.
Our Super Duplex Steel S32760 Forgings are crafted from a premium stainless steel alloy that features about 25% chromium, 7% nickel, 3.5% molybdenum, and nitrogen. This unique composition provides outstanding resistance to pitting, crevice corrosion, and chloride stress corrosion cracking. With a tensile strength ranging from 750 to 930 MPa and impressive impact resistance even in low temperatures, these forgings strike the perfect balance between strength and corrosion protection, making them ideal for demanding operational conditions.
| Standard | ASTM A182, ASME SA182 |
| Specification | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs. |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs. |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs. |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| S32760 | 0.05 max | 1.00 max | 1.00 max | 0.030 max | 0.010 max | 24.00 – 26.00 | 3.00 – 4.00 | 6.00 – 8.00 | 0.20 – 0.30 | 57.61 min |
| Grades | Density (g/cm 3) | Density (lb/in 3) | Melting Point (°C) | Melting Point (°F) |
| S32760 | 7.8 | 0.281 | 1350 | 2460 |
| STANDARD | WERKSTOFF NR. | UNS |
| Super Duplex S32760 | 1.4501 | S32760 |
Yes, Super Duplex Steel S32760 forgings are highly suitable for offshore and marine applications due to their excellent corrosion resistance, high strength, and resistance to pitting, crevice corrosion, and chloride stress cracking.
Welding processes compatible with Super Duplex Steel S32760 forgings include Tungsten Inert Gas (TIG), Metal Inert Gas (MIG), and Shielded Metal Arc Welding (SMAW), using matching filler materials to maintain corrosion resistance.
Super Duplex Steel S32760 forgings are governed by ASTM A182, ASTM A240, ASME SA-182, and EN 10088-3 standards, ensuring quality, corrosion resistance, and mechanical properties for demanding industrial applications.
You’ll find Super Duplex Steel S32760 Forgings in a variety of applications, including offshore platforms, subsea equipment, flanges, valves, pump bodies, pressure vessels, and heat exchangers. Their remarkable mechanical properties and resilience against harsh environments make them perfect for components that face high mechanical loads and corrosive fluids. By using these forgings, you can reduce maintenance needs, enhance operational efficiency, and prolong service life in critical applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Sahil Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Riyadh, Saudi Arabia
