Sahil Metals, a well-respected manufacturer and supplier based in Riyadh, Saudi Arabia, is committed to delivering top-notch stainless steel products that adhere to international standards. One standout item in their specialized lineup is the Stainless Steel 430 Flat Bar, which is prized for its corrosion resistance, durability, and affordability. Crafted with precision, these bars are perfect for both structural and decorative uses across various industries. Thanks to their impressive performance in mildly corrosive environments, Stainless Steel 430 Flat Bars from Sahil Metals are in high demand in the construction, automotive, architectural, and industrial sectors, establishing the company as a reliable supplier in the area.
The Stainless Steel 430 Flat Bar is a ferritic stainless steel primarily made of iron, with chromium content between 16–18%. It also includes trace amounts of carbon, manganese, silicon, phosphorus, and sulfur. The chromium gives it excellent resistance to oxidation and corrosion in mildly aggressive settings. In terms of mechanical properties, it boasts a tensile strength of about 450–600 MPa, a yield strength of around 275 MPa, an elongation of 22%, and a hardness of up to 183 Brinell. With its good formability, machinability, and thermal conductivity, Stainless Steel 430 Flat Bars are well-suited for applications that require moderate strength and corrosion resistance.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 430 | 0.12 | 18.0 | 1.25 | – | 0.06 | 0.15 | 1.00 |
| Element | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness (Brinell (HB) max) |
| SS 430 | 552 | 379 | 25 | 262 |
| Flat Bar | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.49 | 1.60 |
| 18 | 0.62 | 2.02 |
| 20 | 0.76 | 2.49 |
| 22 | 0.92 | 3.02 |
| 25 | 1.19 | 3.90 |
| 28 | 1.49 | 4.89 |
| 28 | 1.49 | 4.89 |
| 30 | 1.71 | 5.61 |
| 32 | 1.95 | 6.38 |
| 36 | 2.46 | 8.08 |
| 38 | 2.74 | 9.00 |
| 40 | 3.04 | 9.97 |
| 45 | 3.85 | 12.62 |
| 50 | 4.75 | 12.62 |
| 56 | 8.96 | 19.55 |
| 60 | 6.84 | 22.44 |
| 65 | 8.03 | 26.34 |
| 70 | 9.31 | 30.54 |
| 75 | 10.69 | 35.06 |
| 80 | 12.16 | 39.89 |
| 90 | 15.39 | 50.49 |
| 100 | 19 | 62.34 |
These bars are commonly found in situations where moderate corrosion resistance, durability, and cost-effectiveness are key. They’re frequently used in architectural structures, kitchen equipment, automotive trims, decorative panels, and appliances. Their magnetic properties and resistance to oxidation make them ideal for furnace components, heat exchangers, and industrial machinery. Additionally, they find applications in interior design, cladding, and food processing equipment. With their excellent formability and dependable performance, Stainless Steel 430 Flat Bars are a versatile choice for both industrial and commercial uses across a range of sectors.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
