Sahil Metals, based in Riyadh, Saudi Arabia, stands out as a top manufacturer and supplier of high-quality Monel 400 Bars and Rods. Known for their remarkable corrosion resistance, durability, and strength, Monel 400 is a nickel-copper alloy crafted to excel in harsh, corrosive, and marine settings. With its impressive ability to withstand seawater, acids, and alkalis, these bars and rods find extensive use in industries like marine engineering, chemical processing, and oil & gas. At Sahil Metals, precision manufacturing and rigorous quality control ensure that their Monel 400 Bars and Rods consistently meet international standards for long-lasting performance.
Monel 400 Bars and Rods are made up of roughly 63% nickel and 28–34% copper, along with trace amounts of iron, manganese, silicon, and carbon. This unique blend gives them a tensile strength of about 550–620 MPa, a minimum yield strength of 240 MPa, and an elongation of up to 30–40%. The alloy showcases excellent corrosion resistance, especially in marine and chemical environments, while also maintaining toughness across a broad temperature range, even in sub-zero conditions. With strong resistance to stress corrosion cracking and pitting, Monel 400 Bars and Rods offer exceptional mechanical reliability for demanding applications.
| Standard | ASTM B164, ASME SB164 |
| Round Bar Size | 3mm~ 800mm |
| Square Bar Size | 4mm* 4mm ~100mm* 100mm |
| Flat Bar Size | 2mm ~ 100mm |
| Hex Bar Size | 2mm ~ 100mm |
| Angle Size | 3mm* 20mm* 20mm~ 12mm* 100mm* 100mm |
| Thickness | 50 mm to 6000 mm Long |
| Length | 1 To 6 Meters, Custom Cut Length |
| Form | Round, Square, Hex(A/F), Rectangle, Billet, Ingot, Forging Etc |
| Grade | Ni | Fe | C | Mn | Si | Cu | Al | S |
| Monel 400 | 63.0 min | 1.0 – 2.5 | 0.3 max | 2.0 max | 0.5 max | 28.0 – 34.0 | 0.50 max | 0.02 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80000 , MPa – 550 | Psi – 35000 , MPa – 240 | 40 % |
| STANDARD | WERKSTOFF NR. | UNS | GOST | AFNOR | JIS | BS | EN |
| Monel 400 | 2.4360 | N04400 | МНЖМц 28-2,5-1,5 | NU-30M | NW 4400 | NA 13 | NiCu30Fe |
Yes, Monel Alloy 400 Bars are highly corrosion-resistant, especially in seawater and acidic environments. Their excellent resistance to pitting, crevice corrosion, and stress corrosion cracking makes them ideal for harsh conditions.
Yes, Monel 400 rods can be customized in size and length according to specific requirements. They are available in various diameters and lengths to suit different industrial applications.
Monel Alloy 400 Bars and Rods perform well in high-temperature environments, maintaining strength and resistance to oxidation. They can withstand temperatures up to 1,000°F (538°C) without significant degradation.
Monel 400 Bars and Rods are widely used in industries requiring excellent corrosion resistance and strength. They are ideal for marine engineering, making components like propeller shafts, seawater valves, and pump shafts. In chemical and hydrocarbon processing, they are used for heat exchangers, reactors, and piping systems due to their resistance to acidic and alkaline environments. The aerospace industry employs them for fuel and water tanks, while the oil and gas sector uses them for drilling tools and downhole equipment. Their exceptional durability and thermal resistance also make them suitable for electrical and electronic components in harsh conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
