Sahil Metals is a Riyadh, Saudi Arabia-based established manufacturer and supplier of high-performance forged parts to industries needing strength and corrosion resistance. The organization is specialized in Duplex Steel S31803 forgings, which boast outstanding mechanical properties and greater resistance to corrosion and stress cracking. Sahil Metals provides services to industries like oil and gas, marine, petrochemicals, and power generation, providing products of international standards. Precise, reliable, and on-time delivery of services is the guarantee of Sahil Metals, being a reliable supplier of long-lasting and reliable forged products under challenging conditions.
Duplex Steel S31803 is a nitrogen-alloyed duplex stainless steel with an approximate composition of 22% chromium, 5-6.5% nickel, 3-3.5% molybdenum, and trace amounts of nitrogen and manganese. This alloy provides an austenite-ferrite balanced microstructure and high strength with high strength, outstanding pitting and crevice corrosion resistance, and weldability. Mechanically, it has a tensile strength of about 620 MPa, yield strength of 450 MPa, and superior toughness and fatigue strength. The combined corrosion resistance and strength position S31803 well for forgings in severe environments, such as chloride-rich or offshore environments.
| Specifications | ASTM A182, ASME SA182 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| S31803 | 0.030 max | 2.00 max | 1.00 max | 0.030 max | 0.020 max | 22.0 – 23.0 | 3.0 – 3.5 | 4.50 – 6.50 | 0.14 – 0.20 | 63.72 min |
| Grades | Density (g/cm 3) | Density (lb/in 3) | Melting Point (°C) | Melting Point (°F) |
| S31803 | 7.805 | 0.285 | 1420 – 1465 | 2588 – 2669 |
| STANDARD | WERKSTOFF NR. | UNS |
| Duplex Steel S31803 | 1.4462 | S31803 |
The maximum operating temperature for Duplex Steel S31803 forgings is typically around 300°C (572°F). Beyond this temperature, the material may experience reduced strength and susceptibility to stress corrosion cracking.
Duplex Steel S31803 forgings are available in various sizes, including diameters ranging from 10 mm to 800 mm, and shapes like round, square, billets, blocks, and custom configurations, based on application needs.
Yes, S31803 Duplex Steel forgings are highly resistant to corrosion, especially in chloride-rich environments. They offer excellent protection against pitting, crevice, and stress corrosion cracking, making them ideal for harsh industrial applications.
Duplex Steel S31803 forgings find widespread use in applications where high strength and corrosion resistance are needed. These comprise items in heat exchangers, pressure vessels, valves, flanges, manifolds, and shafts in chemical, marine, and oil and gas applications. The alloy withstands very high mechanical stress and chloride-bearing environments. Its resistance to pitting, crevice corrosion, and stress corrosion cracking makes it a preferred choice for seawater systems, offshore platforms, and chemical processing plants. S31803 forgings offer durability, long service life, and reliable performance under demanding operational conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
