Sahil Metals, located in Riyadh, Saudi Arabia, stands out as a top-notch manufacturer and supplier of premium metal products, including Copper C10200 Bars and Rods. They’ve built a solid reputation for their dedication to quality, precision, and on-time delivery, catering to a variety of industries like electrical, electronics, plumbing, and manufacturing. Their Copper C10200 Bars and Rods are crafted from high-purity electrolytic tough pitch (ETP) copper, which guarantees excellent electrical and thermal conductivity, impressive corrosion resistance, and remarkable durability. Thanks to their advanced manufacturing techniques and rigorous quality control, Sahil Metals provides dependable and cost-effective copper solutions across Saudi Arabia and the Middle East. Sahil Metals based in Riyadh, Saudi Arabia is a leading supplier of high-quality metal products. And among our extensive offerings Copper C10200 bar and rods stand out. For its excellent purity and versatility. These solid copper forms known for their excellent electrical conductivity, thermal properties and resistance to corrosion. Are crucial in a diverse range of applications. We make sure that their C10200 Copper Bars and Rods meet rigorous industry standards for the customers. With reliable materials for their demanding projects requiring superior performance and high-quality copper.
Copper C10200 Bars and Rods are primarily made of electrolytic tough pitch copper with a purity level of 99.9% or higher. This unique composition offers outstanding electrical and thermal conductivity, typically exceeding 97% IACS (International Annealed Copper Standard). In terms of mechanical properties, they boast a tensile strength ranging from 210-350 MPa, a yield strength of about 33-100 MPa, and an elongation rate between 30-50%. The material is incredibly ductile and exhibits excellent corrosion resistance, making it perfect for electrical and thermal applications that demand high conductivity and mechanical reliability.
| Specifications | ASTM B187, ASTM B301 / ASME SB187, SB301 |
| Range | 3.17 MM TO 350 MM DIA |
| Form | Round, Square, Hex (A/F), Rectangle, Wire (Coil Form), Wire-mesh, Billet, Ingot, Forging Etc. |
| Copper Grades | C10200 |
| Melting Point – Solidus ⁰F | 1981 |
| Melting Point – Liquidus ⁰F | 1981 |
| Density lb/cu in. at 68⁰F | 0.323 |
| Electrical Conductivity % IACS at 68⁰F | 101 |
| Specific Gravity | 8.94 |
| Specific Heat Capacity Btu/lb/⁰F @ 68 ⁰F | 0.092 |
| Thermal Conductivity Btu/sq ft/ft hr/ ⁰F at 68⁰F | 226 |
| Coefficient of Thermal Expansion 10-6 per ⁰F (68-392 ⁰F) | 9.6 |
| Modulus of Rigidity ksi | 6400 |
| Coefficient of Thermal Expansion 10-6 per ⁰F (68-212 ⁰F) | 9.4 |
| Modulus of Elasticity in Tension ksi | 17000 |
| Coefficient of Thermal Expansion 10-6 per ⁰F (68-572 ⁰F) | 9.8 |
| Standards | Country | Value |
|---|---|---|
| EN | Europe | Cu-OF |
| DIN CEN/TS 13388 | Germany | CW008A |
| UNS | – | C10200 |
| JIS | Japan | C1020 |
| GB | China | TU1 |
| BS | England | C102 |
| Thermal Properties | Metric | English |
|---|---|---|
| Annealing Point | >= 371 °C | >= 700 °F |
| CTE, linear | 17.0 µm/m-°C @Temperature 20.0 – 100 °C | 9.44 µin/in-°F @Temperature 68.0 – 212 °F |
| 17.7 µm/m-°C @Temperature 20.0 – 300 °C | 9.83 µin/in-°F @Temperature 68.0 – 572 °F | |
| 17.3 µm/m-°C @Temperature 20.0 – 200 °C | 9.61 µin/in-°F @Temperature 68.0 – 392 °F | |
| Thermal Conductivity | 391 W/m-K @Temperature 20.0 °C | 2710 BTU-in/hr-ft²-°F @Temperature 68.0 °F |
| Melting Point | 1083 °C | 1981 °F |
| Specific Heat Capacity | 0.385 J/g-°C @Temperature 20.0 °C | 0.0920 BTU/lb-°F @Temperature 68.0 °F |
| Property/unit | Condition | Min | Max |
|---|---|---|---|
| Tensile Strength (N/mm2) | 1/2H | 290 | |
| Elongation in 5.65 Cross sectional area | O | 32 | |
| Tensile Strength (N/mm2) | H | 350 | |
| Tensile Strength (N/mm2) | O | 260 | |
| Elongation in 5.65Cross sectional area | 1/2H | 4 |
Yes, Copper C10200 Bars and Rods are fully recyclable. Copper retains its properties after recycling, making it an environmentally friendly and sustainable material for repeated use in various industries.
Copper C10200 Bars and Rods generally do not require corrosion protection coatings as copper naturally resists corrosion. However, in certain aggressive environments, protective coatings may be used to enhance durability.
Yes, Copper C10200 Bars and Rods can be welded using techniques like TIG and MIG welding. Their high conductivity and low oxygen content ensure strong and reliable welds for various applications.
You’ll find Copper C10200 Bars and Rods widely utilized in electrical wiring, busbars, switchgear components, transformers, and electrical connectors, all thanks to their superior conductivity and durability. They’re also popular in plumbing, heat exchangers, and the manufacturing of precision-machined parts where top-notch thermal performance is crucial. With their high ductility and corrosion resistance, C10200 copper is an excellent choice for both industrial and commercial applications, including electronics, power distribution, and HVAC systems, ensuring long-lasting and efficient performance.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Sahil Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Riyadh, Saudi Arabia
